OPERATING AND MAINTENANCE MANUAL PART 2
THE USER SHOULD KEEP THIS DOCUMENT
1. INTRODUCTION
This instruction manual is split into two booklets: PART 1,
containing general information regarding our whole product
range; and PART 2, containing information specifi c to the
motor-driven pump you have purchased. The two publica-
tions are complementary to each other, so make sure you
have both.
Comply with the instructions contained in them to get the
most out of your motor-driven pump and assure its proper
operation. If you need further information, get in touch with
your nearest authorized dealer.
If information in the two parts contradict each other, take
PART 2 containing the product’s specifi c information as
valid.
NO PART OF THESE ILLUSTRATIONS AND/OR TEXT MAY BE
REPRODUCED FOR ANY REASON.
The following symbols have been used in the compilation of
this instruction booklet:
WARNING
Risk of damaging the pump or system
Risk of causing injury or damaging property
Electrical hazard
2. CONTENTS
1. INTRODUCTION page 3
2. CONTENTS page 3
3.
DESCRIPTION AND USE OF MOTOR-DRIVEN PUMP
page 3
4. SPECIFICATIONS page 3
5. PREPARING FOR USE page 3
6. DIAGRAMS AND DRAWINGS page 19
3. DESCRIPTION AND USE OF MOTOR-DRIVEN PUMP
3.1. DESCRIPTION
Description MOTOR-DRIVEN SURFACE PUMPS
MODEL / Type LPS / Vertical in-line centrifugal
3.2. USE FOR WHICH PUMPS ARE DESIGNED
For handling of clean water, water and glycol solutions and
other liquids compatible with AISI 304 steel in general (do-
mestic, commercial and industrial circulation, heating, cool-
ing and air-conditioning systems; handling of hot sanitary
water, low-pressure liquids).
Use the motor-driven pump based on its technical specifi ca-
tions.
3.3. USE FOR WHICH PUMPS ARE NOT DESIGNED
Pumps cannot be used to handle dirty water, water contain-
ing acids and corrosive liquids in general, water with tem-
peratures higher than those mentioned in chap. 4, saltwater,
fl ammable liquids and hazardous liquids in general.
The motor-driven pumps must never be made to work with-
out liquid, and must always operate below the maximum
suction pressures (see chap. 4).
4. SPECIFICATIONS
4.1. PUMP SPECIFICATIONS
U/M LPS
Max. temperature
of liquid pumped
°C 100
Suction diameter
[mm] 25-32-40-50
Delivery diameter
Maximum suction
working pressure
MPa
0.2 (25 and single phases)
0.4 (32-40-50)
4.2. MOTOR SPECIFICATIONS
TYPE TEFC
RATINGS
See motor-driven pump rating
plate
OVERLOAD
PROTECTION
SINGLE PHASE: thermal cutout w/
automatic reset
THREE PHASE: by installer
4.3. INFORMATION ON AIRBORNE NOISE
The mean sound pressure level (A-weighted) measured 1m
from the pump is less than 70dB(A).
5. PREPARING FOR USE
5.1. FILLING THE PUMP (FIG. 1)
WARNING
OPERATION TO BE PERFORMED WITH THE
MOTOR’S TERMINAL STRIP FULLY CLOSED.
LPS
a) Unscrew the hexagonal caps (1) (chap. 6 FIG. 1) located
above the pump casing at the side of the delivery and
suction fl anges;
b) with the aid of a funnel, fi ll the pump casing with water to
overfl owing;
c) screw the hexagonal caps back on until they are locked
tight to prevent air getting in.
