18
574
Probe Connections
12
10
11
Open the battery compart-
ment and set the switches
ON or Off according to the
desired probe type.
(10) NTC - thermistor
(11) TC - thermocouple
(12) Thermocouple type J
(13) Thermocouple type K
P
ROBE
CONNECTIONS
13
Connect the probe to the
input (U). Press MODE,
until the desired probe
symbol (7) appears. The
probe temperature is
shown in the lower part of
the display (6). The real
time infrared temperature
is shown in the main
display (3).
U
7
6
3
