Fluke 574 [7/32] Symbols and safety markings
![Fluke 574 [7/32] Symbols and safety markings](/views2/1005377/page7/bg7.png)
7
574
Symbol Explanation
Risk of danger. Important information. See
Manual.
Risk of danger. Important information. See
Manual.
Risk of danger. Important information. See
Hazardous voltage. Precedes warning
Warning. Laser.
Conforms to requirements of European Union
and European Free Trade Association (EFTA)
Conforms to requirements of European Union
and European Free Trade Association (EFTA)
Conforms to requirements of European Union
°
C
Celsius
°
F
Fahrenheit
Battery
Symbols and Safety Markings
K
1
The laser sight simplifies
sighting of the measure-
ment object. It
shows the
spot size that includes the
measured target.
To turn the laser on or off
press the LASER button
(K) when the trigger is
pulled. Alaser symbol (1)
appears when the laser is
on.
The laser automatically
turns of
f if you release the
trigger.
LASER
K
1
