93
Safety
Ref.
No.
Part No.
Part Name & Description Q'ty Remarks
23 TPD0E2131 BOTTOM CUSHION 1 PAVCCZ
24 TPD0E2139 PEDESTAL CUSHION 1 PAVCCZ
25 TPDX0016-1 JOINT FOR PEDESTAL 1
26 TPE0E4047 SET BAG 1 PAVCCZ
27 TPE0E9002 ACCESSORIES BAG 1 PAVCCZ
28 TPE0E9003 BAG FOR AC CORD 1 PAVCCZ
TPEB336 BAG (STAND POLE R) 1
29 TPEB338 BAG (STAND ACCESSORY) 1 PAVCCZ
30 TPEB368 BAG (PEDESTAL STAND) 1
TPG0E9530 PAPER CAP 0.25 PAVCCZ
31 TQB0E0939 INSTRUCTION BOOK(ENGLISH) 1 PAVCCZ B
31 TQB0E0940A INSTRUCTION BOOK(GERMAN) 1 PAVCCZ E
31 TQB0E0940B INSTRUCTION BOOK(DUTCH) 1 PAVCCZ E
31 TQB0E0940C INSTRUCTION BOOK(ITALIAN) 1 PAVCCZ E
31 TQB0E0940D INSTRUCTION BOOK(FRENCH) 1 PAVCCZ E
31 TQB0E0940E INSTRUCTION BOOK(SPANISH) 1 PAVCCZ E
31 TQB0E0940F INSTRUCTION BOOK(SWEDISH) 1 PAVCCZ E
31 TQB0E0940G INSTRUCTION BOOK(NORWEGIAN) 1 PAVCCZ E
31 TQB0E0940H INSTRUCTION BOOK(FINNISH) 1 PAVCCZ E
31 TQB0E0940I INSTRUCTION BOOK(LITHUANIAN) 1 PAVCCZ E
31 TQB0E0940J INSTRUCTION BOOK(PORTUGUESE) 1 PAVCCZ E
31 TQB0E0940K INSTRUCTION BOOK(DANISH) 1 PAVCCZ E
31 TQB0E0940M INSTRUCTION BOOK(BULGARIAN) 1 PAVCCZ E
31 TQB0E0940N INSTRUCTION BOOK(ROMANIAN) 1 PAVCCZ E
31 TQB0E0940O INSTRUCTION BOOK(LATVIAN) 1 PAVCCZ E
31 TQB0E0940P INSTRUCTION BOOK(POLISH) 1 PAVCCZ E
31 TQB0E0940Q INSTRUCTION BOOK(HUNGARIAN) 1 PAVCCZ E
31 TQB0E0940R INSTRUCTION BOOK(CZECH) 1 PAVCCZ E
31 TQB0E0940S INSTRUCTION BOOK(GREEK) 1 PAVCCZ E
31 TQB0E0940T INSTRUCTION BOOK(TURKISH) 1 PAVCCZ E
31 TQB0E0940U INSTRUCTION BOOK(ENGLISH) 1 PAVCCZ E
31 TQB0E0940W INSTRUCTION BOOK(SLOVAKIAN) 1 PAVCCZ E
31 TQB0E0940Z INSTRUCTION BOOK(ESTONIAN) 1 PAVCCZ E
31 TQB0E09419 OIB(KAZAKHSTAN) 1 PAVCCZ R
31 TQB0E0941L OIB(RUSSIAN) 1 PAVCCZ R
31 TQB0E0941Y OIB(UKRAINIAN) 1 PAVCCZ R
32 TQB0E0940X INSTRUCTION BOOK(CD-ROM) 1 PAVCCZ E
TQZJ201 SCREW USE HANDBILL 1 PAVCCZ
41 TSXL519 CABLE (C10-C20) 1
42 TSXM060-1 CABLE (A20-SC20) 1 PAVCCZ
43 TSXM061 CABLE (A31-C11) 1 PAVCCZ
44 TSXM062 CABLE (A32-C21) 1 PAVCCZ
51 TTU0E0744 REAR COVER 1 PAVCCZ E
