94
Safety
Ref.
No.
Part No.
Part Name & Description Q'ty Remarks
51 TTU0E0750 REAR COVER 1 PAVCCZ R
51 TTU0E0753 REAR COVER 1 PAVCCZ B
52 TUX0E152 42HANGER METAL 2 PAVCCZ
53 TXFEA01LWUE SPEAKER ASSY 2 PAVCCZ
54 TXFKP01LGUE SIDE TERMINAL COVER ASSY 1 PAVCCZ
55 TXFKY01LUUE CABINET ASSY 1 PAVCCZ
TXJA11LWUE SPEAKER LEAD(A11-SPL/SPR) 1 PAVCCZ
XSB3+6FJ SCREW(HDMI:3) 2
XSB4+6FN BIND SCREW 2
XTB4+12GFJ SCREW(GH:20 PW:2 LED:1) 17
XTB4+12GFJK SCREW(BC:11) 11
XTB4+12GFN SCREW (4*12) 4
XTV3+10JFJK SCREW(REAR AV:2) 2
XTW3+10TFJ SCREW 1
XYN3+F10FJK SCREW(BC-AC_INLET:2) 2
XYN3+J10FJ SCREW 17
XYN4+E6FJ SCREW(INLET:1) 1
XYN4+F10FJ SCREW(AL-GHT:4) 18
XYN4+F10FJ SCREW(SM:4) 4
XYN4+F10FJ SCREW(KARI-HANGER METAL:4) 4
XYN5+F18FN SCREW(5x18) 4
XZB7.5X9D05 POLY BAG (SCREW) 1
XZB9X18C05 BAG (STAND POLE L) 1
XZBT6506 POLY BAG(INSTRUCTION BOOK) 1
