97
C3019 F1G1C104A116 C 0.10UF, K, 16V 1
C3020 ECJ1VB1A105K C 0.01UF, Z, 10V 1
C3021 ECJ1VB1A105K C 0.01UF, Z, 10V 1
C3022 ECJ1VB1A105K C 0.01UF, Z, 10V 1
C3023 ECJ1VB1A105K C 0.01UF, Z, 10V 1
C3024 F1J1A106A087 C 0.010UF, K,
10V
1
C3025 F1J1A106A087 C 0.010UF, K,
10V
1
C3026 F1J1A106A087 C 0.010UF, K,
10V
1
C3031 ECJ1VB1A105K C 0.01UF, Z, 10V 1
C3032 ECJ1VB1A105K C 0.01UF, Z, 10V 1
C3108 F1G1E333A091 C 0.033UF, K,
25V
1
C3109 F1G1E333A091 C 0.033UF, K,
25V
1
C3119 EEEHB1C101P C 100PF, J, 16V 1
C3120 EEEHB1C101P C 100PF, J, 16V 1
C3121 EEEHB1C101P C 100PF, J, 16V 1
C3122 EEEHB1C101P C 100PF, J, 16V 1
C3123 F1J1A106A087 C 0.010UF, K,
10V
1
C3124 F1J1A106A087 C 0.010UF, K,
10V
1
C3125 F1J1A106A087 C 0.010UF, K,
10V
1
C3126 F1J1A106A087 C 0.010UF, K,
10V
1
C3127 F1J1A106A087 C 0.010UF, K,
10V
1
C3128 F1J1A106A087 C 0.010UF, K,
10V
1
C3129 F1J1A106A087 C 0.010UF, K,
10V
1
C3130 F1G1C104A116 C 0.10UF, K, 16V 1
C3131 F1J1A106A087 C 0.010UF, K,
10V
1
C3132 F1J1A106A087 C 0.010UF, K,
10V
1
C3133 F1G1H561A730 C 56UF, 50V 1
C3134 F1G1H561A730 C 56UF, 50V 1
C3135 F1G1H561A730 C 56UF, 50V 1
C3136 F1G1H561A730 C 56UF, 50V 1
C3137 F1G1H561A730 C 56UF, 50V 1
C3138 F1G1H561A730 C 56UF, 50V 1
C3139 F1G1H561A730 C 56UF, 50V 1
C3140 F1G1H561A730 C 56UF, 50V 1
C3141 F1J1A106A087 C 0.010UF, K,
10V
1
C3142 F1J1A106A087 C 0.010UF, K,
10V
1
C3143 F1J1A106A087 C 0.010UF, K,
10V
1
C3144 F1J1A106A087 C 0.010UF, K,
10V
1
C3145 F1J1A106A087 C 0.010UF, K,
10V
1
C3146 F1J1A106A087 C 0.010UF, K,
10V
1
C3147 F1J1A106A087 C 0.010UF, K,
10V
1
C3148 F1J1A106A087 C 0.010UF, K,
10V
1
C3149 ECJ1VB1A105K C 0.01UF, Z, 10V 1
C3150 ECJ1VB1A105K C 0.01UF, Z, 10V 1
C3151 ECJ1VB1A105K C 0.01UF, Z, 10V 1
C3152 ECJ1VB1A105K C 0.01UF, Z, 10V 1
C3153 F1G1H561A730 C 56UF, 50V 1
C3154 F1G1H561A730 C 56UF, 50V 1
C3155 F1G1H561A730 C 56UF, 50V 1
C3156 F1G1H561A730 C 56UF, 50V 1
C3157 ECJ1VB1A105K C 0.01UF, Z, 10V 1
C3158 ECJ1VB1A105K C 0.01UF, Z, 10V 1
C3159 F1J1A106A087 C 0.010UF, K,
10V
1
C3160 F1J1A106A087 C 0.010UF, K,
10V
1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
C3161 F1J1A106A087 C 0.010UF, K,
10V
1
C3162 F1J1A106A087 C 0.010UF, K,
10V
1
C3163 F1J1A106A087 C 0.010UF, K,
10V
1
C3164 F1J1A106A087 C 0.010UF, K,
10V
1
C3165 F1J1A106A087 C 0.010UF, K,
10V
1
C4546 ECJ1VB0J105K C 1UF, K, 6.3V 1
C4547 ECJ1VB0J105K C 1UF, K, 6.3V 1
C4660 ECJ1VB0J105K C 1UF, K, 6.3V 1
C4661 ECJ1VB0J105K C 1UF, K, 6.3V 1
C4662 ECJ1VB0J105K C 1UF, K, 6.3V 1
C4663 ECJ1VB0J105K C 1UF, K, 6.3V 1
C4664 ECJ1VB0J105K C 1UF, K, 6.3V 1
C4665 ECJ1VB0J105K C 1UF, K, 6.3V 1
C4666 ECJ1VB0J105K C 1UF, K, 6.3V 1
C4667 ECJ1VB0J105K C 1UF, K, 6.3V 1
C4701 F1G1C104A116 C 0.10UF, K, 16V 1
C4702 F1G1C104A116 C 0.10UF, K, 16V 1
C4704 F1G1C104A116 C 0.10UF, K, 16V 1
C4705 F1G1C104A116 C 0.10UF, K, 16V 1
C5000 F1G1C104A116 C 0.10UF, K, 16V 1
C5001 F1G1C104A116 C 0.10UF, K, 16V 1
C5002 F1G1C104A116 C 0.10UF, K, 16V 1
C5003 F1G1C104A116 C 0.10UF, K, 16V 1
C5004 F1G1H102A730 C 1000UF, 50V 1
C5050 F1J1A475A087 C 4.7UF, K, 10V 1
C5052 F2G1A221A149 E 220UF, 10V 1
C5055 F1G1C104A116 C 0.10UF, K, 16V 1
C5058 ECJ1VB0J105K C 1UF, K, 6.3V 1
C5100 F1G1C104A116 C 0.10UF, K, 16V 1
C5101 F1H1A474A084 C 0.47UF, 50V 1
C5155 F1J0J106A004 C 0.010UF, K,
16V
1
C5156 F1J0J106A004 C 0.010UF, K,
16V
1
C5157 F1J0J106A004 C 0.010UF, K,
16V
1
C5158 F1J0J106A004 C 0.010UF, K,
16V
1
C5159 F1J0J106A004 C 0.010UF, K,
16V
1
C5160 F1J0J106A004 C 0.010UF, K,
16V
1
C5471 F1G1C104A116 C 0.10UF, K, 16V 1
C5472 F1G1C104A116 C 0.10UF, K, 16V 1
C5600 F1K1E106A136 C 10UF, Z, 25V 1
C5601 F1K1E106A136 C 10UF, Z, 25V 1
C5602 F1G1E682A123 C 6800UF, Z, 25V 1
C5603 F1K1E106A136 C 10UF, Z, 25V 1
C5604 F1K1E106A136 C 10UF, Z, 25V 1
C5606 F1G1A154A053 C0.015UF, K, 10V 1
C5607 F1J1A475A087 C 4.7UF, K, 10V 1
C5608 F1H1C104A143 C 0.1UF, K, 16V 1
C5609 F1H1C104A143 C 0.1UF, K, 16V 1
C5611 F1J1E105A231 C 1 UF 25V 1
C5612 F1H1C105A145 C 0.01UF, K, 16V 1
C5615 F1H1A225A051 C 22UF, 50V 1
C5616 F1G1E103A123 C 0.010UF, K,
25V
1
C5617 F1K0J226A008 C 22UF, K,6.3V 1
C5618 F1K0J226A008 C 22UF, K,6.3V 1
C5619 F1K0J226A008 C 22UF, K,6.3V 1
C5620 F1K0J226A008 C 22UF, K,6.3V 1
C5621 F1K0J226A008 C 22UF, K,6.3V 1
C5622 F1K0J226A008 C 22UF, K,6.3V 1
C5625 F1K1E106A136 C 10UF, Z, 25V 1
C5626 F1K1E106A136 C 10UF, Z, 25V 1
C5627 F1G1A393A053 C0.015UF, K, 10V 1
C5628 F1K1E106A136 C 10UF, Z, 25V 1
C5629 F1K1E106A136 C 10UF, Z, 25V 1
C5631 F1G1C104A116 C 0.10UF, K, 16V 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
