99
C8414 F1G1E103A123 C 0.010UF, K,
25V
1
C8415 F1G1C104A116 C 0.10UF, K, 16V 1
C8600 F1G1H102A730 C 1000UF, 50V 1
C8853 F1G1C104A116 C 0.10UF, K, 16V 1
C8854 F1G1C104A116 C 0.10UF, K, 16V 1
C8860 F2G1C470A022 E 47UF, 16V 1
C8861 F1G1C104A116 C 0.10UF, K, 16V 1
C8862 F1G1C103A116 C 0.010UF, K,
16V
1
C8863 F1J0G226A001 C 0.001UF, 6.3V 1
C8922 F1G1C104A116 C 0.10UF, K, 16V 1
C8923 F1G1C104A116 C 0.10UF, K, 16V 1
C8950 F1G1C103A116 C 0.010UF, K,
16V
1
C9040 F1G1C104A116 C 0.10UF, K, 16V 1
C9052 F1G1C104A116 C 0.10UF, K, 16V 1
C9066 F1K0J226A008 C 22UF, K,6.3V 1
C9067 F1G1H561A730 C 56UF, 50V 1
C9069 F1G1H561A730 C 56UF, 50V 1
C9100 F1J1A106A087 C 0.010UF, K,
10V
1
C9101 F1G1E103A123 C 0.010UF, K,
25V
1
C9102 F1K1E106A136 C 10UF, Z, 25V 1
C9103 F1G1E103A123 C 0.010UF, K,
25V
1
C9106 F1K1E106A136 C 10UF, Z, 25V 1
C9108 F1G1E103A123 C 0.010UF, K,
25V
1
C9116 F1G1C104A116 C 0.10UF, K, 16V 1
C9300 F1G1C104A116 C 0.10UF, K, 16V 1
C9301 F1G1H150A731 C 15UF, 50V 1
C9302 F1G1H180A731 C 18UF, 50V 1
C9303 F1G1C104A116 C 0.10UF, K, 16V 1
C9307 F1G1C104A116 C 0.10UF, K, 16V 1
C9308 F1G1C104A116 C 0.10UF, K, 16V 1
C9311 F1G1C104A116 C 0.10UF, K, 16V 1
C9312 F1J1A106A087 C 0.010UF, K,
10V
1
C9313 F1G1C104A116 C 0.10UF, K, 16V 1
C9314 F1J1A106A087 C 0.010UF, K,
10V
1
C9315 F1G1C104A116 C 0.10UF, K, 16V 1
C9316 F1J1A106A087 C 0.010UF, K,
10V
1
C9319 F1G1C104A116 C 0.10UF, K, 16V 1
C9322 F1G1C104A116 C 0.10UF, K, 16V 1
C9323 F1G1C104A116 C 0.10UF, K, 16V 1
C9325 F1G1C104A116 C 0.10UF, K, 16V 1
C9327 F1G1C104A116 C 0.10UF, K, 16V 1
C9335 F1J1A106A087 C 0.010UF, K,
10V
1
C9336 F1J1A106A087 C 0.010UF, K,
10V
1
C9337 F1J1A106A087 C 0.010UF, K,
10V
1
C9339 F1G1C104A116 C 0.10UF, K, 16V 1
C9340 F1G1C104A116 C 0.10UF, K, 16V 1
C9342 F1G1C104A116 C 0.10UF, K, 16V 1
C9344 F1G1C104A116 C 0.10UF, K, 16V 1
C9347 ECJ1VB0J105K C 1UF, K, 6.3V 1
C9349 F1J1A106A087 C 0.010UF, K,
10V
1
C9350 F1G1C104A116 C 0.10UF, K, 16V 1
C9351 F1G1C104A116 C 0.10UF, K, 16V 1
C9352 ECJ1VB0J105K C 1UF, K, 6.3V 1
C9356 F1G1C104A116 C 0.10UF, K, 16V 1
C9361 F1G1C104A116 C 0.10UF, K, 16V 1
C9363 F1G1C104A116 C 0.10UF, K, 16V 1
C9371 F1J1A106A087 C 0.010UF, K,
10V
1
C9372 F1J1A106A087 C 0.010UF, K,
10V
1
C9373 F1J1A106A087 C 0.010UF, K,
10V
1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
C9374 F1G1C104A116 C 0.10UF, K, 16V 1
C9375 F1G1C104A116 C 0.10UF, K, 16V 1
C9380 F1G1C104A116 C 0.10UF, K, 16V 1
C9383 F1G1C104A116 C 0.10UF, K, 16V 1
C9391 F1J1A106A087 C 0.010UF, K,
10V
1
C9392 F1J1A106A087 C 0.010UF, K,
10V
1
C9394 F1G1C104A116 C 0.10UF, K, 16V 1
C9400 F1G1C104A116 C 0.10UF, K, 16V 1
C9401 F1G1C104A116 C 0.10UF, K, 16V 1
C9402 F1G1C104A116 C 0.10UF, K, 16V 1
C9800 F1H1E104A129 C 0.1UF, 25V 1
C9801 F1G1E682A123 C 6800UF, Z, 25V 1
C9803 F1G1E472A123 C 4200UF, Z, 25V 1
C9804 F1K1E106A136 C 10UF, Z, 25V 1
C9805 F1K1E106A136 C 10UF, Z, 25V 1
C9806 F1G1H101A731 C 100PF, K, 50V 1
C9807 F1G1H201A731 C 200 UF, K, 50V 1
C9809 F1G1H102A730 C 1000UF, 50V 1
C9811 F1G1C104A116 C 0.10UF, K, 16V 1
C9812 F1K1E106A136 C 10UF, Z, 25V 1
C9813 F1K1E106A136 C 10UF, Z, 25V 1
C9814 F1K0J226A008 C 22UF, K,6.3V 1
C9815 F1K0J226A008 C 22UF, K,6.3V 1
C9816 F1G1E103A123 C 0.010UF, K,
25V
1
C9825 F1K0J226A008 C 22UF, K,6.3V 1
C9827 F1K1E106A136 C 10UF, Z, 25V 1
C9828 F1K1E106A136 C 10UF, Z, 25V 1
C9829 F1G1C104A116 C 0.10UF, K, 16V 1
C9830 F1G1E103A123 C 0.010UF, K,
25V
1
C9831 F1G1H272A730 C 2700UF, 50V 1
C9834 F1K0J226A008 C 22UF, K,6.3V 1
C9835 F1K0J226A008 C 22UF, K,6.3V 1
C9900 F1G1E103A123 C 0.010UF, K,
25V
1
CN0102 K1KA11A00178 11P CONNECTOR 1
D1101 B0JCCE000008 DIODE 1
D2014 B0ACCJ000048 DIODE 1
D2520 B3AGB0000060 LED 1 PAVCCZ
D2870 B0JCME000092 DIODE 1
D3123 DZ2J140M0L ZENER DIODE 1 PAVCCZ
D3124 DZ2J140M0L ZENER DIODE 1 PAVCCZ
D3129 B0ACCJ000048 DIODE 1
D3130 B0ACCJ000048 DIODE 1
D3300 K7AAAY000006 PHOTO LINK 1
D4702 B0ACCJ000048 DIODE 1
D4704 B0JCCE000008 DIODE 1
D4719 B0ACCJ000048 DIODE 1
D4721 B0JCCE000008 DIODE 1
D5000 B0ADCJ000100 DIODE 1
D5051 B0JCME000076 DIODE 1
D5052 B0ACCJ000048 DIODE 1
D5100 B0ADEJ000035 ZENER DIODE 1
D5471 B0ACCJ000048 DIODE 1
D5472 B0ADEJ000035 ZENER DIODE 1
D5475 B0ADCJ000100 DIODE 1
D5476 DZ2J068M0L ZENER DIODE 1 PAVCCZ
D5477 DZ2J068M0L ZENER DIODE 1 PAVCCZ
D5478 B0ADCJ000100 DIODE 1
D5479 B0ADCJ000100 DIODE 1
D5480 B0ADCJ000100 DIODE 1
D5481 DZ2J120M0L ZENER DIODE 1
D5482 DZ2J120M0L ZENER DIODE 1
D5483 DZ2J068M0L ZENER DIODE 1 PAVCCZ
D5484 DZ2J068M0L ZENER DIODE 1 PAVCCZ
D5485 DZ2J068M0L ZENER DIODE 1 PAVCCZ
D5486 DZ2J068M0L ZENER DIODE 1 PAVCCZ
D5602 DZ2J056M0L ZENER DIODE 1
D5605 B0HCMM000014 DIODE 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
