Name and function of each part
6
No. Name No. Name
1
HOST RS-485 connection
20
RESET button
2
HOST RS-485 terminating resistance switch
21
AUX IN (0, 1) connection
3
INIT button
22
CoreStation power connection (DC 12V IN)
4
Ethernet connection
23
Relay 3 connection
5
Relay 1 connection
24
TTL input (6, 7) or supervised input (6, 7) connection
6
TTL input (2, 3) or supervised input (2, 3) connection
25
TTL output (6, 7) connection
7
TTL output (2, 3) connection
26
Wiegand 3 connection
8
Wiegand 1 connection
27
12V output
9
12V output
28
RS-485 3 connection
10
RS-485 1 connection
29
RS-485 3 terminating resistance switch
11
RS-485 1 terminating resistance switch
30
CoreStation status LED
12
Relay 0 connection
31
Relay 2 connection
13
TTL input (0, 1) or supervised input (0, 1) connection
32
TTL input (4, 5) or supervised input (4, 5) connection
14
TTL output (0, 1) connection
33
TTL output (4, 5) connection
15
Wiegand 0 connection
34
Wiegand 2 connection
16
12V output
35
12V output
17
RS-485 0 connection
36
RS-485 2 connection
18
RS-485 0 terminating resistance switch
37
RS-485 2 terminating resistance switch
19
RTC battery
• Press and hold the INIT button for 2 seconds or longer to initialize the Corestation currently linked with a device and connect it to a different device.
• The power output (12V, up to 1.5A) of CoreStation can be used as the power for a Wiegand device when CoreStation and the Wiegand device are
connected. In other words, when 3 Wiegand devices that consume 200mA are connected, a device that consumes up to 900mA can be connected
to the remaining power output terminal.
Communication status LED
LED Status
HOST RS-485 TX
Orange flashing: Transmitting RS-485 data
HOST RS-485 RX
Green flashing: Receiving RS-485 data
RELAY (0 ~ 3)
Red lighting: Relay operation
SUPERVISED INPUT (0 ~ 7)
TTL input
• Green lighting: Normal Close
• Off: Normal Open
Supervised Input
• Green lighting: Normal Close (short circuit), Normal Open, Switch On
• Off: Switch Off
AUX IN (0, 1)
Orange lighting: Receiving AUX signal
Note
