Name and function of each part
7
CoreStation status LED
The status of CoreStation can be confirmed through STATUS LED 1 / 2 located on the left side from the front unit of the product. These
status LEDs show the status of Ethernet, RS-485 0, RS-485 1, RS-485 2, RS-485 3, RS-485 HOST, and system in order for 1 second each.
Feature LED 1 LED 2 Status
Ethernet
Red
Red
Connection to a dynamic IP failed.
Red
Yellow
Connection to a dynamic IP is on standby.
Red
Sky blue
Connection to a static IP succeeded.
Red
Blue
Connection to a dynamic IP succeeded
Red
Purple
Connection to a static IP failed.
Red
Off
HW error
RS-485 0
Yellow
Red
No slave device
Yellow
Yellow
The slave device is disconnected.
Yellow
Blue
The slave device is normal.
Yellow
Off
HW error
RS-485 1
Green
Red
No slave device
Green
Yellow
The slave device is disconnected.
Green
Blue
The slave device is normal.
Green
Off
HW error
RS-485 2
Sky blue
Red
No slave device
Sky blue
Yellow
The slave device is disconnected.
Sky blue
Blue
The slave device is normal.
Sky blue
Off
HW error
RS-485 3
Blue
Red
No slave device
Blue
Yellow
The slave device is disconnected.
Blue
Blue
The slave device is normal.
Blue
Off
HW error
RS-485 HOST
Purple
Red
No slave device
Purple
Yellow
The slave device is disconnected.
Purple
Blue
The slave device is normal.
Purple
Off
HW error
System
White
Red
System locked (by trigger & action of device)
White
Yellow
System locked (by trigger & action of BioStar 2)
White
Green
Connection to BioStar 2 succeeded
White
Sky blue
Connection to BioStar 2 succeeded + Tamper ON
White
Blue
Tamper ON
White
Purple
System locked (by trigger & action of device) + Tamper ON
White
White
System locked (by trigger & action of BioStar 2) + Tamper ON
