IKA color squid white 0003671000 [10/44] Accessories
![IKA color squid white 0003671000 [10/44] Accessories](/views2/1545025/page10/bga.png)
isopropyl alcohol
Foodstuffs water containing tenside
Fuels water containing tenside
- Do not allow moisture to get into the appliance when
cleaning.
- Wear protective gloves during cleaning the devices.
- Before using another than the recommended method for
cleaning or decontamination, the user must as certain
with IKA that this method does not destroy the instru-
ment.
IKA - stirring bars:
TRIKA
®
25
IKAFLON
®
20 (recommendation)
IKAFLON
®
30
Stirring bar remover
In accordance with IKA warranty conditions, the warranty
period is 24 months. For claims under the warranty please
contact your local dealer. You may also send the machine
direct to our factory, enclosing the delivery invoice and giving
reasons for the claim. You will be liable for freight costs.
The warranty does not cover worn out parts, nor does it
apply to faults resulting from improper use, insufficient care
or maintenance not carried out in accordance with the
instructions in this operating manual.
- Set the knob to the left stop
- Place a magnetic rod in a vessel which is penetrable
for magnetic field lines and fill the vessel with the
medium to be processed.
- Place the vessel on the centre of the base plate.
- Connect the appliance to a socket (the voltage stated
on the nameplate must correspond to the mains
voltage).
All elements of the display will flash briefly. All impor-
tant safety functions will be tested. Subsequently, the
software-version is indicated. The appliance is opera-
ble after this check.
- Set the speed using the knob
The displayed value will flash until the desired motor speed
is reached.
The appliance is maintenance-free.
Cleaning
Only use cleansing agents which have been recommended
by IKA.
Use to remove:
Dyes Isopropyl alcohol
construction materials water containing tenside,
isopropyl alcohol
Cosmetics water containing tenside,
Starting up
Maintenance
Accessories
Warranty
10
