16
17
ICC basic and control
/// Compact immersion circulators
The compact immersion circulator ICC basic and the ICC control are designed for tem-
pering fluids up to + 150 °C and thus provide an economic and attractive solution for
standard applications, such as the tempering of samples. The ergonomic handle and
the compact design allow for safe transport as well as convenient use. The integrated
base provides a secure stand while protecting floaters and tubular heating elements. A
bracket for mounting the bath vessel is included in the scope of delivery. The compact
ICC immersion circulators allow for simple and flexible exchange of different baths.
The ICC circulators from IKA are ready to connect to a pump connection set (PCS.ICC)
for external tempering as well as to a cooling coil (CC2) for operation at and below
ambient temperature.
USB/RS 232 interfaces for connecting
a PC, using labworldsoft and enabling
online updates of device software.
Integrated base protects tubular
heating elements and floaters.
ICC control – graphic display showing
parameters such as temperature, pump
speed, etc.
ICC control – integrated
PT 100 temperature probe interface.
ICC control
Compact immersion circulator
Convenient carrying handle
Integrated base protects
tubular heating elements
and floaters.
