CDA

DUAL IMPELLER CENTRIFUGAL ELECTRIC PUMPS

in cast iron

C

ast iron dual impeller centrifugal electric pumps

APPLICATIONS

• Pressure boosting domestic plants

PUMP TECHNICAL DATA

• Maximum working pressure:

- 6 bar for CDA 0.75 - 1.00

- 10 bar for the rest of the range

• Maximum temperature of the liquid 40°C for CDA 0.75 - 1.00, 90°C

for the rest of the range

• G1 suction connection for CDA 0.75 - 1.00

• G1¼ for CDA 1.50 - 2.00 - 3.00, G1½ per CDA 4.00 - 5.50

• G1 discharge connection for CDA 0.75 - 1.00 - 1.50 - 2.00 - 3.00

G1¼ for CDA 4.00 - 5.50

230/400V ±10%, 50Hz three phase voltage

• Permanent capacitor inserted and thermo-amperometric protection

with automatic rearm incorporated for the single phase motor

• Protection under user's responsibility for the three phase version

MATERIALS

• Cast iron pump casing

• Mechanical seal in Carbon/Ceramic/NBR

• Impeller in PPE+PS reinforced with glass fibres for CDA 0.75 - 1.00, in

brass for the rest of the range

• Shaft in AISI 303 for CDA 0.75 - 1.00 -1.50 - 2.00 - 3.00, in AISI 304

• 1EPBH

ACCESSORIES (on request)

• 5 litre 10 bar ¾ EPDM vessel

• 24 litre 8 bar 1” EPDM vessel

• 24 litre 10 bar 1” EPDM vessel

• PVC 5m key float with counter-weight

• PVC 10m key float with counter-weight

• SQUARE-D FSG-2 1.4÷4.6 bar G¼ F pressure switch

• FYG-22 2.8÷7 bar G¼ F pressure switch

• Presscomfort - Pressure regulator

IDENTIFICATION CODE

CDA 1.50

M
