Ebara CDA 2.00T [4/4] Dual impeller centrifugal electric pumps

Your Life, our Quality. Worldwide. Commercial

The contents of this publication must not be regarded as binding. EBARA Pumps Europe S.p.A. reserves the right to effect any modification it deems necessary, without prior notice.

CDA

DUAL IMPELLER CENTRIFUGAL ELECTRIC PUMPS

in cast iron

ELECTRIC DATA TABLE

Model P

2

Efficiency Capacitor Efficiency (%) P

1

Absorbed Current

Single phase Three phase Single phase Three phase [A]

CDA 1.50 M CDA 1.50 T 1,5 1,1 - IE2 40 450 79,7 82,5 83,0 1,85 1,80 8,6 5,5 3,2

CDA 2.00 M CDA 2.00 T 2 1,5 - IE2 40 450 80,3 83,4 83,8 2,35 2,25 10,8 7,8 4,5

- CDA 3.00 T 3 2,2 - IE2 --83,0 84,4 83,8 - 2,74 - 8,5 4,9

- CDA 4.00 T 43 - IE2 --83,1 86,3 86,8 - 4,10 - 12,5 7,2

- CDA 5.50 T 5,5 4- IE2 --84,3 87,2 87,8 - 4,56 - 15,1 8,7

M

ECHANICAL SEAL

M

ATERIALS TABLE

Ref. Name Material

A

Rotating part Ceramic

Spring AISI 316

G Structure/frame AISI 304

Single phase Three phase ØA ØB C

CDA 0.75 M CDA 0.75 T 15 26 29

CDA 1.00 M CDA 1.00 T 15 26 29

CDA 1.50 M CDA 1.50 T 18 30,9 32

CDA 2.00 M CDA 2.00 T 18 30,9 32

230V 230/400V [HP] [kW]

CDA 0.75 M CDA 0.75 T 0,75 0,55

<70

CDA 1.00 M CDA 1.00 T 1 0,75

CDA 1.50 M CDA 1.50 T 1,5 1,1

CDA 2.00 M CDA 2.00 T 2 1,5

- CDA 3.00 T 3 2,2

- CDA 4.00 T 43

- CDA 5.50 T 5,5 4

* Mean value of several measures at 1m distance around the pump.

Tollerance ± 2,5 dB.
