Thomas Genius Aquafilter [15/48] Dust vacuuming

General instructions

To connect up suction hose

– Insert the suction hose connection piece in the appliance connector

and turn backwards until it locks.

To remove suction hose

– Press the button on the connection piece. Turn the connection piece

a quarter of a turn to the side and draw out.

Parking position

– Hang the suction tube complete with nozzle and hose in the suction

tube holder on the back of the appliance.

- Should the appliance be stored in the upright position hang the

suction tube on the bottom of the appliance.

Electronic suction power control

Switch the appliance on/off by gently pressing the TOUCH-TRONIC

key.

- Press down the key briefly:

Appliance switches on; rating 850 Watt (ECO stage);

green indicator lamp comes on

- Hold down key:

Infinitely variable electronic suction power control

between 650 and 1600 Watt

Signal lamp green: MIN. 650 Watt to 1125 Watt;

Signal lamp yellow: 1125 Watt to MAX. 1600 Watt.

The signal lamp goes out briefly when reaching the minimum or maxi-

mum capacity.

– Press key briefly again:

Appliance turns off.

The AQUAFILTER system offers particularly good filtration at

a rating between 850 W (ECO stage) and MAX 1600 W.

Consequently only use the appliance at MIN rating (650 Watt)

for a short time (when vacuuming curtains, for example).

Mechanical suction power control

The suction power can also be adjusted by means of the mechanical

suction power controller (auxiliary air slide).

Auxiliary air slide closed = full suction power

Auxiliary air slide open = reduced suction power.

The auxiliary air slide must always be closed when using the

electronic suction power control system.

Dust vacuuming

Information for use

● Do not use the GENIUS AQUAFILTER for dry vacuuming when

the AQUAFILTER system has not been appropriately fitted accor-

ding to the operating instructions. This could cause damage to the

appliance.

● Do not suck up any liquids when dry vacuuming.

● Do not suck up any large quantity of fine dust, for example, cho-

colate powder, flour, etc.

To make the AQUA filter ready for use

Your GENIUS AQUA FILTER is set ready for dry vacuuming at the

works.

Open appliance cover by lifting up the cover catch.

Draw out the AQUA filter from the dirty water tank by means

of the grip. Fill up the dirty water tank with 1 litre of clean

water.

Insert the complete AQUA filter up to the stop behind the two

guide ribs of the dirty water tank.

At the same time make sure that the wet filter is fitted and the

circumventing AQUA filter seal is tight up against the inside of

the dirty water tank.

Connect up suction hose and fit telescopic suction tube. Connect the

required accessory.

To achieve optimal filtration we recommend rinsing out the

AQUA filter quickly with clear water after approx. 40-60

minutes continuous operation or when a large number of

drops of water can be seen on the underside of the cover.

You should also change the water in the dirty water tank.

For hygienic reasons the AQUAFILTER system is to

be emptied and cleaned every time the appliance

is used. Dirty water and moist parts propagate the

growth of bacteria and fungi (see cleaning and main-

tenance instructions).

To suck up liquids

Information for use

You can suck up spilled, non-hazardous water-based liquids

(for example, water, coffee, etc.) with the THOMAS GENIUS

AQUAFILTER.

● Caution! Petrol, thinners, heating oil, etc., can develop explosive

vapour and mixtures when mixed with the intake air.

● Acetone, acids and solvents can attack the materials used to pro-

duce the appliance. Clean and dirty water can be sucked up wit-

hout any hesitation.

● Clean and dry the dirty water tank and all the used parts after

sucking up liquids.

● Never suck up liquids without the dirty water tank.

● Your THOMAS GENIUS AQUAFILTER is not suitable for sucking up

larger quantities of liquid from containers or basins.

● Empty and clean the appliance every time it is used for wet clea-

ning. Dirty water and moist parts propagate the growth of bacte-

ria and fungi (see cleaning and maintenance instructions).

Put the 2-piece anti-swash insert together.

Draw out the AQUA filter from the dirty water tank by the grip

and insert the anti-swash insert.

Remove the HEPA filter from the appliance.

Insert the anti-swash insert and dirty water tank in the

appliance. Make sure that both the wet filter (10a) and the

motor protection filter (12) are fitted.

Connect up suction hose.

Select a suitable nozzle and fit it on the respective suction tube or

hand grip.

Pull the mains power plug and cable out of the appliance and connect

up.

Switch on the appliance and set for maximum suction power.

Make sure that the mechanical suction power control (21) is comple-

tely closed.
