![Clarion CC2001E [5/10] English](/views2/1003411/page5/bg5.png)
284-0877-01
CC-2011E 5
English
4. OPERATION
Operation when using Clarion rear-view camera system
The rear-view image is displayed when the transmission is placed into reverse, or when the manual
switch is operated.
Troubleshooting
The following symptoms are not malfunctions. Before having the unit serviced, check the following
points once more.
Symptom
No image
Poor image is
produced
Reason
Wiring is incomplete or disconnected.
A fuse is burned out.
The lens cover is soiled.
Sunlight or headlights from a vehicle
in the rear are shining directly in the
camera.
The environment is too dark.
The level of illumination outside the
vehicle changed too abruptly.
1. When moving from a bright to a
dark location (especially from
bright sunlight to shade), the
image may appear excessively
dark.
2. When moving from a dark to a
bright location (especially from
shade into bright sunlight), the
screen image may appear
excessively bright.
Solution
Check wiring once again and confirm
correct connections.
When using an independent power
supply box, check the fuse and, if
burned out, replace with a new one
of the same capacity (1 A). If the fuse
burns out repeatedly, consult your
dealer or nearest Clarion Service
Center.
Wipe lightly with a damp soft cloth.
Do not rub harshly with dry cloths
since scratches may be produced.
The image will return to normal when
the light striking the lens is removed.
The image display will be poor at
night or in dim light.
The image will return to normal in
conditions of brighter illumination.
[When using a separate power
supply box]
• In auto mode
Stop the vehicle and set the
transmission to neutral, then once
again to reverse.
• In manual mode
Press the AUTO/MANUAL switch to
set the unit to AUTO, then press once
again to set to MANUAL. If the
transmission is in reverse, set it to
neutral before pressing the switch.
