Temperature Calibrator
Maintenance
37
postage paid and insured, to the nearest Service Center.
Fluke assumes no responsibility for damage in transit.
The Fluke 724 Temperature Calibrator covered by the
warranty will be promptly repaired or replaced (at Fluke’s
option) and returned to you at no charge. See the
warranty at the beginning of this manual for warranty
terms. If the warranty period has expired, the calibrator
will be repaired and returned for a fixed fee. If the
calibrator is not covered under the warranty terms,
contact an authorized service center for a price quote for
repair.
To locate an authorized service center, refer to
“Contacting Fluke” at the beginning of the manual.
Replacement Parts
Table 7 lists the part number of each replaceable part.
Refer to Figure 18.
Table 7. Replacement Parts
Item Description PN Qty.
1 Case top 664232 1
2 LCD mask 1548383 1
3 Elastomeric strips 802063 2
4 Input/output bracket 1549221 1
5 LCD bracket 667287 1
6 Mounting screws 494641 11
7 Backlight 690336 1
8 LCD 690963 1
9 Keypad 1548126 1
10 Case bottom 664235 1
11 AA alkaline batteries 376756 4
12 Case screws 832246 4
13 Battery door 664250 1
14 Accessory mount 658424 1
15 Tilt stand 659026 1
16 Battery door 1/4-turn
fasteners
948609 2
17 TL75 series test leads 855742 1
18 Test lead, red
Test lead, black
688051
688066
1
1
19 724 Product Overview
Manual
1547851 1
20 AC72 alligator clip, red
AC72 alligator clip, black
1670641
1670652
1
1
21 CD-ROM (includes the 724
Users Manual)
1547849 1
22 Top case decal 1548329 1
23 Fuse 0.05A/250V 2002234 1
