DR-701D
D01334100A 1217.MA-2487A
ENGLISH
New functions in firmware version 2.00
The following new function has been added in firmware version 2.00.
0
Ambisonic mode added
0
Menu Screen operation added
0
Support for 4-channel poly files added
Ambisonic mode added
The unit must be set to ambisonic mode when using an ambisonic mic to
record.
Ambisonic mode settings
Make ambisonic mode settings on the new AMBISONICS page.
REC MODE
This sets the ambisonic recording mode.
options: OFF , A FORMAT , B FORMAT
B FORMAT
This sets the recording format, when the REC MODE is set to B FORMAT.
options: FuMa , AmbiX
POSITION
This sets the orientation of the ambisonic mic.
Option Meaning
UPRIGHT
Use when recording with the mic pointed up
UPSIDEDOWN
Use when recording with the mic pointed down
ENDFIRE
Use when recording with the mic pointed forward
UPSIDEDOWNUPRIGHT ENDFIRE
Menu screen changes when ambisonic mode is on
When ambisonic mode is set to A FORMAT or B FORMAT, the menu screens
shown will change as follows.
0
Menu items shown
Page name Page name
1
INPUT
9
TIME CODE
2
AMBISONICS MODE
10
SLATE TONE
3
LEVEL CONTROL
11
HDMI AUDIO ASSIGN
4
OUTPUT LEVEL
12
METER / TRIM
5
RECORD
13
POWER MANAGEMENT
6
REC SETTING
14
REMOTE
7
FILE
15
SYSTEM
8
MEDIA
0
Menu items not shown
i
SEL item on INPUT page
INPUT is fixed to IN 1-2 and IN 3-4.
i
MIXER page
The mixer function is disabled.
i
PHASE/DELAY page
The mic distance delay compensation and input phase reversal functions
are disabled.
i
AUTO item on LEVEL CONTROL page
The automatic level control function is disabled.
i
TRIM GANG page
When ambisonic mode is set to A FORMAT or B FORMAT, operating
knob 1 will affect the TRIM values of all inputs (1–4).
i
MIC POWER page
PHAN and VOLTAGE phantom power settings from the MIC POWER
page are shown on the INPUT page, and the plug-in power function is
disabled.
NOTE
i
On the following pages, using knob 1 will operate all channels. (There are
no settings for individual channels.)
i
GAIN item on INPUT page
i
LEVEL CONTROL page When the LIM. item is set to ON, it will operate
with four channels linked.
i
The REC SETTING page SAMPLE item cannot be set to 192kHz.
i
If recording is conducted with the REC SETTING page FORMAT item set to
BWF 16bit or BWF 24bit, the AMBISONIC page setting will be recorded.
i
The REC SETTING page FILE TYPE item options become MONO and POLY
(STEREO cannot be selected). The default value will be changed from
MONO to POLY.
Names of files recorded in ambisonic mode
Files recorded in ambisonic mode will be named in the following manner.
0
When recorded with B Format set to FuMa
TASCAM_FuMaB_0001.wav
Monitoring changes when ambisonic mode is on
When ambisonic mode is set to A FORMAT or B FORMAT, the monitoring that
can be selected will change as follows.
Option Meaning
STEREO MIX
Sound in the 45° range in front of the ambisonic mic is
converted to stereo for monitoring.
FLU
Input sound is monitored from the front/upper left (Front Left
Up) mic capsules (as seen in UPRIGHT orientation).
FRD
Input sound is monitored from the front/lower right (Front
Right Down) mic capsules (as seen in UPRIGHT orientation).
BLD
Input sound is monitored from the back/lower left (Back Left
Down) mic capsules (as seen in UPRIGHT orientation).
BRU
Input sound is monitored from the back/upper right (Back
Right Up) mic capsules (as seen in UPRIGHT orientation).
W
The B format W audio is monitored.
X
The B format X audio is monitored.
Y
The B format Y audio is monitored.
Z
The B format Z audio is monitored.
CAMERA IN
The CAMERA IN jack signal is monitored.
FLU+FRD
The input FLU sound is monitored in the left channel and the
input FRD sound is monitored in the right channel.
BLD+BRU
The input BLD sound is monitored in the left channel and the
input BRU sound is monitored in the right channel.
Meter display when Ambisonic mode is on
When Ambisonic mode is on, the meters correspond to the audio as shown in
the following table.
1 2 3 4
A format FLU FRD BLD BRU
B format (FuMa) W X Y Z
B format (AmbiX) W Y Z X
Menu Screen operation added
When the Menu Screen is open, press and hold the MENU button again to
return to the INPUT page.
Support for 4-channel poly files added
The REC SETTING page FILE TYPE item 6ch option has been changed to
POLY.
When set to POLY
When the RECORD page MIX item is set to OFF, 4-channel poly files will be
created.
When set to ON, 6-channel poly files including the MIX will be created. When
4-channel poly files are created, “_4ch” will be added to the end of the file
name (“_6ch” will be added to the end of 6-channel poly files).
