TASCAM US-2x2/US-4x4
17
8 – Using the Software Mixer (for Windows)
Opening the Software Mixer
Open the Software Mixer in the following manner.
CAUTION
Be careful not to open “US-2x2 & US-4x4 Settings Panel” in
the same folder by mistake. If the Settings Panel is open,
close it before opening the Software Mixer.
8
Windows 10
Click the Windows Start button and select “All Programs” w
“TASCAM” w “US-2x2 & US-4x4 Software Mixer”.
8
Windows 8.1
Left-click the Start button to open the Start screen. Click the
button to open the Apps screen, and select “US-2x2 &
US-4x4 Software Mixer” under “TASCAM”.
8
Windows 7
Click the Windows Start button and select All Programs w
TASCAM w US-2x2 & US-4x4 Software Mixer.
Software Mixer overview
In addition to the Settings Panel explained in the “Settings Panel
overview” on page 13, the Software Mixer also adds items
7 through 0. Items other than 7 through 0 can also be set
using the Settings Panel.
Software Mixer
7 Mixer Ver.
This shows the Software Mixer version.
8 MODE item
This sets the operation mode of the unit.
Options
“DAW”
Use this setting when using DAW software, as well as
when you do not need “BROADCAST/KARAOKE” mode (for
live broadcasting or karaoke applications).
“BROADCAST/KARAOKE”
Use this setting for live broadcasting, karaoke and similar
applications.
Use this setting to automatically enable the loopback
function. This mixes the sound output from the computer
with the sounds of mics input through the IN1 and IN2
jacks on the unit and sends the mix back to the computer.
i Click the “Detail” button to open the DETAIL settings screen.
9 External Effects (ASIO)
To use an echo on mics and other signals input to the unit by
using an external effect, check the “External Effects (ASIO)”
checkbox (4).
CAUTION
Depending on the broadcast software settings, the signal
could loop and cause feedback.
NOTE
Even if you have removed the check from the “External
Effects (ASIO)” checkbox (4), the check (4) will automati-
cally be added when you select DAW mode.
0 Stereo Output
Use to set whether the output signal is handled as mono or
stereo.
Options
“Off” (default)
Only the audio from the left side can be handled when
using some applications. When using an application like
this, audio from the right side cannot be transmitted or
recorded. In this case, remove the check (4) to mix both
left and right signals to mono and transmit that sound to
the computer.
“On”
If the application supports stereo, add the check (4) to
transmit the stereo sound to the computer.
NOTE
If the check (4) is removed, all stereo input signals will be
converted to mono. This setting receives priority even if
“STEREO” is selected (DETAIL screen 5) for mic input.
