Problem Possible cause Possible solution
The dishes are wet. The programme had no dry-
ing phase.
Set a programme with the
drying phase.
The dishes are wet
and matt.
The rinse aid dispenser is
empty.
Make sure that there is rinse
aid in the rinse aid dispenser.
The quality of the rinse aid
can be the cause.
Try a different brand of rinse
aid.
The quality of the combi de-
tergent tablets can be the
cause.
• Try a different brand of
combi detergent tablets.
• Activate the rinse aid dis-
penser and use the rinse
aid together with the combi
detergent tablets.
Activating the rinse aid dispenser
with the multitab option activated
1. Press the on/off button to activate the
appliance.
2.
Open the menu option.
3. Go to Settings .
4. Press OK to open the submenu.
5. Go to Rinse aid and activate the rinse
aid dispenser.
6. Press OK to confirm.
7. Press the display touchpad to close the
menu option.
10. TECHNICAL INFORMATION
Dimensions Width / Height / Depth (mm) 596 / 818 - 898 / 575
Electrical connection Refer to the rating plate.
Voltage 220-240 V
Frequency 50 Hz
Water supply pressure Min. / max. (bar / MPa) (0.5 / 0.05 ) / (8 / 0.8 )
Water supply
1)
Cold water or hot water
2)
max. 60 °C
Capacity Place settings 12
1)
Connect the water inlet hose to a water tap with a 3/4'' thread.
2)
If the hot water comes from alternative sources of energy, (e.g. solar panels, aeolian energy),
use the hot water supply to decrease energy consumption.
11. ENVIRONMENT CONCERNS
Recycle the materials with the symbol
.
Put the packaging in applicable containers
to recycle it.
Help protect the environment and human
health and to recycle waste of electrical
and electronic appliances. Do not dispose
appliances marked with the symbol
with
the household waste. Return the product
to your local recycling facility or contact
your municipal office.
18
www.electrolux.com
symbol. Dispose of the packaging in recycling containers.
Help protect the environment and human health and recycle waste from electric and electronic
appliances.
Do not dispose of appliances marked with the
Problem Possible cause Possible solution
The dishes are wet. The programme had no dry-
ing phase.
Set a programme with the
drying phase.
The dishes are wet
and matt.
The rinse aid dispenser is
empty.
Make sure that there is rinse
aid in the rinse aid dispenser.
The quality of the rinse aid
can be the cause.
Try a different brand of rinse
aid.
The quality of the combi de-
tergent tablets can be the
cause.
• Try a different brand of
combi detergent tablets.
• Activate the rinse aid dis-
penser and use the rinse
aid together with the combi
detergent tablets.
Activating the rinse aid dispenser
with the multitab option activated
1. Press the on/off button to activate the
appliance.
2.
Open the menu option.
3. Go to Settings .
4. Press OK to open the submenu.
5. Go to Rinse aid and activate the rinse
aid dispenser.
6. Press OK to confirm.
7. Press the display touchpad to close the
menu option.
10. TECHNICAL INFORMATION
Dimensions Width / Height / Depth (mm) 596 / 818 - 898 / 575
Electrical connection Refer to the rating plate.
Voltage 220-240 V
Frequency 50 Hz
Water supply pressure Min. / max. (bar / MPa) (0.5 / 0.05 ) / (8 / 0.8 )
Water supply
1)
Cold water or hot water
2)
max. 60 °C
Capacity Place settings 12
1)
Connect the water inlet hose to a water tap with a 3/4'' thread.
2)
If the hot water comes from alternative sources of energy, (e.g. solar panels, aeolian energy),
use the hot water supply to decrease energy consumption.
11. ENVIRONMENT CONCERNS
Recycle the materials with the symbol
.
Put the packaging in applicable containers
to recycle it.
Help protect the environment and human
health and to recycle waste of electrical
and electronic appliances. Do not dispose
appliances marked with the symbol
with
the household waste. Return the product
to your local recycling facility or contact
your municipal office.
18
www.electrolux.com
symbol with normal household refuse. Take the
product to the nearest recycling point or contact your local authority.
Subject to changes
