8
EN
9
fee mill”).
N.B.! Useoriginalormanufacturerrecommendedacces-
sories and spare parts only.
Designated use
This appliance is designed and made to prepare coee and heat
drinks.
All other use is considered improper.
This appliance is not suitable for commercial use.
The manufacturer is not liable for damage deriving from impro-
per use of the appliance.
This appliance can be installed over a built-in oven if the latter
is tted with a cooling fan at the rear (maximum microwave
power: 3 kW).
Instructions
Read these instructions carefully before using the appliance.
• Keeptheseinstructions
• Failuretorespecttheseinstructionsmayresultinburnsor
damage to the appliance.
The manufacturer is not liable for damage deriving from
failure to respect these instructions.
N.B.! The appliance has a cooling fan.
This comes on whenever coee, steam or hot water is delivered.
After several minutes, the fan goes o automatically.
DESCRIPTION
Description of the appliance
(page 3 - A)
A1. Cup tray
A2. Service door
A3. Coee guide
A4. Waste coee container
A5. Brewing unit
A6. Cup tray lights
A7. On/OFF/stand-by button
A8. Control panel
A9. Jug
A10. Hot water and steam nozzle
A11. IEC connector
A12. Water tank
A13. Coee spout (adjustable height)
A14. Drip tray
A15. Bean container lid
A16. Bean container
A17. Grinding adjustment knob
A18. Pre-ground coee funnel door
A19.Measure
A20. Compartment for measure
A21. Pre-ground coee funnel
A22. Power cable
A23.Mainswitch
A24. Tray
Description of the control panel
(page 3 - B)
N.B.! A light touch is enough to activate the icon.
B1. Display: guides the user in using the appliance.
B2. icon to activate or deactivate menu parameter set-
ting mode
B3. icon to turn lights A6 on and o
B4. icon to select the coee taste
B5. icon to select the type of coee (espresso, small cup,
medium cup, large cup, mug)
B6. icon to exit the selected mode
B7-B8. icons to scroll forwards or backwards through the
menu and display the various modes
B9. OK icon to conrm the selected function
B10. icon to deliver a cup of coee
B11. icon to deliver two cups of coee
B12. icon to deliver cappuccino
B13. icon to deliver hot water
B14. “jug” icon to make a number of cups of coee directly in
the jug (provided)
Description of milk container and accesso-
ries
(page 3 - C)
C1. Frothed milk regulator
C2. Milkcontainerhandle
C3. CLEANbutton
C4. Milkintaketube
C5. Frothed milk spout
C6. Milkfrother
C7. Hot water spout
PRELIMINARY CHECKS
Controls after transport
After removing the packaging, make sure the product is comple-
