Electrolux ECG 6400 [51/212] Cleaning the brewing unit

0 Remove any remaining coffee beans

(you could use the vacuum cleaner

with the hose or crevice tool attach-

ment for this).

If a foreign object is impossible to

remove, contact the Customer Service

Centre. Blocking or damage caused by

foreign objects in the grinder might

be excluded from the guarantee.

Caution! Risk of injury from the mov-

ing grinder. Never switch the coffee

machine on when you are working on

the grinder. This can lead to severe

injuries. Before starting work, ensure

that the machine is unplugged from

the mains socket.

0 Use a small quantity of coffee beans to

test the proper operation of the

grinder by making a cup of coffee. The

first time the grinder is used, or after

cleaning, less ground coffee will enter

the brewing unit, because the channel

first has to be filled. This can influence

the first cup of coffee.

14.4 Cleaning the brewing unit

We advise you to clean the brewing

unit regularly (depending on how fre-

quently it is used). If your coffee

machine is to be left unused for some

time (e.g. holidays), empty the waste

coffee container and the water tank,

and thoroughly clean the coffee

machine, including the brewing unit.

Proceed as follows:

0 Turn the appliance off by pressing the

"On/Off" key (Fig. 11) (do not unplug)

and wait for the display to go off.

0 Unlock and open the service door at

the front by pushing the corresponding

opening button (Fig. 30).

0 Remove the drip tray and the waste

coffee container (Fig. 31) and clean

them.

0 Press the two red release buttons on

the brewing unit from the sides, press-

ing towards the centre (Fig. 32), and

pull it out.

Important: The brewing unit can only

be removed if the appliance is turned

off with the ON/OFF key at the

front of the machine. It should not be

disconnected from the mains.

Attempting to remove the brewing

unit when the appliance is on may

cause serious damage.

0 Wash the brewing unit under running

water, without using detergents. Never

wash the brewing unit in the dish-

washer.

0 Clean the inside of the appliance thor-

oughly. To remove coffee encrustations

from the inside of the appliance, scrape

with a plastic or wooden fork or similar

tool that does not scratch the surface

(Fig. 33), then vacuum up the residues

with a vacuum cleaner (Fig. 34).

0 Replace the brewing unit (Fig. 36, a) by

pushing it onto the holder (Fig. 36, b)

and pushing in the pin (Fig. 36, c). The

pin must be inserted into the pipe at

the bottom of the brewing unit

(Fig. 36, d).

0 Push the PUSH symbol (Fig. 36, e)

firmly in until the brewing unit clicks

into place.

0 After having heard the click, check that

the red buttons (Fig. 36, f) have

snapped out, otherwise the service

door cannot be closed.

Fig. 37: The two red buttons have

snapped out correctly.

Fig. 38: The two red buttons have not

snapped out.

0 Replace the drip tray, complete with

the waste coffee container.

0 Close the service door.

If the brewing unit is not inserted cor-

rectly, i.e. when you can hear that it has

clicked into place, and the two red but-

tons have not snapped out correctly,

the service door cannot be closed.

If it is hard to insert the brewing unit,

before inserting it squeeze it to the

right heigth by pressing it firmly from

the top and bottom simultaneously, as

shown in figure 35.
