The coffee flows out of only one of

the dispensers

• The dispenser holes are blocked.

0 Scrape off the dry coffee residues with

a needle (Fig. 29).

When the knob for steam and hot

water is turned, no steam comes out

of the steam nozzle

• The holes in the steam nozzle and the

inner part of the steam nozzle are

clogged.

0 Clean the holes in the steam nozzle

and the inner part of the steam nozzle

(see „Cleaning the steam nozzle“,

page 45).

When the or function is

selected, the appliance does not

deliver coffee, but only water

• The ground coffee may be blocked in

the ground coffee filler.

0 Remove the ground coffee inside the

filler using a knife (see „Using pre-

ground coffee“, page 43) (Fig. 22). Then

clean the brewing unit and the inside

of the appliance (see „Cleaning the

brewing unit“, page 51)

When the button is pressed, the

appliance does not switch on

• The main switch at the back is not

switched on (fig. 8) or the appliance is

not plugged in.

0 Check that the main switch is in the "I“

position and that the power cable is

plugged into the mains socket.

The brewing unit cannot be removed

for cleaning

• The appliance is on. The brewing unit

can only be removed if the appliance is

off.

0 Turn the appliance off and remove the

brewing unit (see „Cleaning the brew-

ing unit“, page 51).

Important: The brewing unit can only

be removed if the appliance is turned

off with the ON/OFF key at the

front. It should not be disconnected

from the mains. Attempting to

remove the brewing unit when the

appliance is on may cause serious

damage.

The coffee does not run out from

the dispenser outlets, but from

around the sides of the service door

• The holes in the dispenser outlets are

clogged with dry coffee.

0 Remove the dried coffee with a needle

(Fig. 29).

• The tilt compartment (R) inside the ser-

vice door is blocked and cannot swing.

0 Thoroughly clean the tilt compartment,

particularly near the hinges, to ensure

they are free to swing smoothly.

Ground coffee was used (not beans)

and the appliance does not deliver

any coffee

• Too much ground coffee has been

added.

0 Remove the brewing unit and thor-

oughly clean the inside of the appli-

ance, as described in „Cleaning the

brewing unit“, page 51. Repeat the

operation using a maximum of 2

scoops of ground coffee.

• The "Coffee strength / Pre-ground cof-

fee" knob has not been turned to the

or position and the appliance

has used both the ground coffee that

has been added and the coffee that has

been ground by the grinder.

0 Thoroughly clean the inside of the

appliance, as described in „Cleaning

the brewing unit“, page 51. Repeat the

operation, first turning the "Coffee

strength / Pre-ground coffee" knob as

described in „Using pre-ground cof-

fee“, page 43.

• Ground coffee has been added when

the appliance was switched off.
