Сервисный мануал Страница: 11

Sony KDL-40X4500 [11/78] Kdl 40x4500

KDL-40/46/55X4500 (HK) 1-2

KDL-40X4500

1-1-3. H1VM BOARD REMOVAL

1-1-4. HEAT SINK REMOVAL

1 Power bracket

2 Power button

3 H1VM board

2 Heat sink

1 Three screws

(+PSW 3X8)
