KDL-40/46/55X4500 (HK) 2
SPECIFICATIONS
Model name KDL-40X4500 KDL-46X4500 KDL-55X4500
System
Analogue: B/G, I, D/K, M
Digital: GB20600-2006
Analogue: PAL, PAL60 (only video input), SECAM, NTSC3.58,
NTSC4.43 (only video input)
Digital: MPEG-2 MP@ML/HL, H.264/MPEG-4 AVC MP/HP@L4
Analogue: B/G: VHF: E2~E12/UHF: E21~E69/CATV: S01~S03, S1~S41
I: UHF: B21~B69/CATV: S01~S03, S1~S41
D/K: VHF: C1~C12, R1~R12/UHF: C13~C57, R21~R60/
CATV: S01~S03, S1~S41, Z1~Z39
M: VHF: A2~A13/UHF: A14~A79/CATV: A-8~A-2, A~W+4,
W+6~W+84
Digital: GB20600-2006
Input/Output jacks
1, 2
Supported formats: 1080p, 1080i, 720p, 576p, 576i, 480p, 480i
Y: 1 Vp-p, 75 ohms, 0.3V negative sync/P
B/CB: 0.7 Vp-p, 75 ohms/
P
R/CR: 0.7 Vp-p, 75 ohms
HDMI IN1, 2, 3, 4
Video: 1080/24p, 1080p, 1080i, 720p, 576p, 576i, 480p, 480i
Audio: Two channel linear PCM: 32, 44.1 and 48 kHz, 16, 20 and 24 bits
Analogue audio input (minijack) (HDMI IN 1 only)
PC Input
Video output (phono jack)
Audio output (phono jacks)
PC audio input (minijack)
USB port
Headphonesjack
LAN
10BASE-T/100BASE-TX connector (Depending on the operating environment of
the network, connection speed may differ. 10BASE-T/100BASE-TX communication
rate and communication quality are not guaranteed for this TV.)
Power and others
Screen size (measured diagonally)
40 inches
(Approx. 101.6 cm)
46 inches
(Approx. 116.8 cm)
55 inches
(Approx. 138.8 cm)
Power
consumption
in “Home”/
“Standard” mode
210 W 270 W 370 W
in “Shop”/“Vivid”
mode
230 W 350 W 380 W
Standby power consumption*
0.3W (19 W when
“Quick Start” is set to
“On”)
0.6 W (20 W when
“Quick Start” is set to
“On”)
0.7 W (22 W when
“Quick Start” is set to
“On”)
LCD (Liquid Crystal Display) Panel
TV system
Colour/video system
Channel coverage
Panel system
Sound output
10 W+ 10 W, 12 W + 12 W (Woofer)
Antenna/cable 75 ohmexternal terminal for VHF/UHF
1S video input (4-pin mini DIN)
1, 2, 3
Video input (phono jacks)
1, 2, 3
Audio input (phono jacks)
DIGITAL AUDIO OUT
(OPTICAL)
Digital optical jack
PC IN (RGB)
PC Input (D-sub 15-pin)
G: 0.7 Vp-p, 75 ohms, non Sync on Green/B: 0.7 Vp-p, 75 ohms/
R: 0.7 Vp-p, 75 ohms/HD: 1-5 Vp-p/VD: 1-5 Vp-p
DMPORT
DIGITAL MEDIA PORT
Power requirements 220 V – 240 V AC, 50 Hz
Display resolution
1,920 dots (horizontal) × 1,080 lines (vertical)
