04 ABB MICRO DRIVES, ACS55, 0.25 TO 3 HP / 0.18 TO 2.2 KW
—
ABB ACS55 micro drives
Compact simplicity for single input power
applications
Feature Advantage Benefit
Worldwide availability and service Drives are available worldwide and stocked in four
regions. Dedicated global service and support
provided by a network that is one of the largest in
the industry.
Fast and reliable delivery with dedicated support to
any country in the world.
Single phase supply Suitable for single-phase residential and
commercial applications.
Avoids cabling and installation costs associated
with three-phase supplies.
Slim design Fits easily into a variety of cabinet designs. Reduced cabinet size or greater packing density can
be achieved.
Several installation alternatives Can be mounted using screws or DIN-rail side-by-
side or sideways.
The same drive type can be used across different
designs, saving time and installation costs.
High switching frequency Reduced motor noise. Lower disturbance to the building’s occupants.
Built-in EMC filter High degree of electromagnetic compatibility.
Category C2 (1
st
environment) RFI filters as
standard.
Low EMC emissions in all environments.
Easy configuration Quick setup and simple configuration Substantial time savings. Minimal expertise needed.
DriveConfig kit available as an
option
Fast, easy and safe configuration of drives without
the need for a power connection. Extended range of
application parameter values and more drive
functionality. Reliable copying of parameter values
from PC to drives.
Substantial time savings. Drive can be configured
without an electrician present. Drive suitable for a
wide range of applications. Reduced risk of errors
during setup.
Wide ambient operating
temperature
Drives can be operated in high ambient
temperatures up to 55 °C degrees (131°F).
One drive series can be used in a wide range of
different environmental conditions.
ABB micro drives
ACS55 micro drives are designed for use in a wide
variety of simple machinery applications where
only single-phase power is available. Feed-
through wiring with power leads entering at the
top and motor cables exiting at the bottom
allows for easy replacement of contactors and
motor starters. These drives improve machine
performance with the combined advantages of
variable speed control and energy savings for
small AC motors.
ACS55 micro drives are compact and offer
multiple mounting positions and options. DIN rail
mounting capability makes them ideal for panel
builders. The drive is quickly programmed using
switches and potentiometers. More advanced
programming is possible using the DriveConfig
kit PC tool.
Ensure speed and control in a variety of low power
applications, such as automatic gate, solar
trackers, treadmills and whirlpool baths. The ACS55
drive is ideal for those situations where a low cost,
easy to install, and simple to operate variable
frequency drive is needed. It’s ready to go for
commercial and residential environments.
Highlights
• Reduce motor noise with high switching
frequency
• Fast programming of unpowered drives
• Optional speed potentiometer and operator
control switch kit
