ABB ACS55-01E-01A4-2 [8/12] Technical data
![ABB ACS55-01E-01A4-2 [8/12] Technical data](/views2/1556658/page8/bg8.png)
08 ABB MICRO DRIVES, ACS55, 0.18 TO 2.2 KW/0.25 TO 3 HP
—
Technical data
Mains connection
Power range 0.25 to 3 hp
Voltage 1-phase, 110 to 120 V and 200 to 240 V, +10/-15%
Frequency 48 to 63 Hz
Motor connection
Voltage 3-phase, from 0 to
U
SUPPLY
(for 110/120 V from 0 to 230 V)
Frequency 0 to 120/130 Hz, 0 to 250 Hz with DriveConfig kit
Overload capacity 150% (60 s)
Motor control method Scalar U/f
Application parameters As standard With DriveConfig kit
Motor nominal frequency 50/60 Hz 40 to 250 Hz
Acceleration time 0.1 to 30 s 0.1 to 100 s
Deceleration time 0.1 to 30 s 0.1 to 100 s
Maximum frequency 50 to 120 Hz 0 to 250 Hz
Relay output Fault/Run Fault/Fault (-1)/Run
Load type Pump/fan or constant
Switching frequency
Standard 5 kHz, adjustable up to 16 kHz with automatic switching frequency reduction
Environmental limits
Ambient temperature
-20 to 40 °C (-4 to 104 °F)
up to 55 °C (131 °F)
With nominal current and 5 kHz switching frequency, no frost allowed
With derating
Altitude
Output current
Nominal current: 0 to 1000 m (0 to 3280 ft) reduced by 1% per 100 m (328 ft) over
1000 m to 2000 m (3280 ft to 6561 ft)
Relative humidity Lower than 95% (without condensation)
Degree of protection IP20
Contamination levels No conductive dust allowed, corrosive liquids or gases (IEC 60721-3-3)
Control connections
One analog input
Voltage signal
Current signal
Potentiometer reference value
Response time
Resolution
Accuracy
0 (2) to 10 V, 200 kΩ single-ended
0 (4) to 20 mA, 100 Ω single-ended
10 V ±2% max. 10 mA, 1 kΩ ≤ R ≤ 10 kΩ
≤ 60 ms
0.1%
±1%
Three digital inputs 12 V DC with internal supply or 12 to 24 V DC external supply, PNP
Input impedance 1.5 Ω
Response time ≤ 9 ms
One relay output
Switching voltage
Maximum continuous current
12 to 250 V AC or max 30 V DC
2 A
Product compliance
Low Voltage Directive 2006/95/EC
EMC Directive 2004/108/EC
Machinery Directive 2006/42/EC
Quality assurance system ISO 9001 and Environmental system ISO 14001
CE, UL, cUL, C-Tick and GOST R approvals
RoHS compliant
