52
FLN Protocol Technical Data
Point Database
The following table lists the point database for FLN / ACH550 (Application 2734).
FLN Point Database
Point
Subpoint Name
Factory
Default
Engr.
Units
Slope Intercept
On Text Off Text
# Type (SI Units)
01 LAO CTLR ADDRESS 99 - 1 0 - -
02 LAO APPLICATION 2734 - 1 - -
{03} LAI FREQ OUTPUT 0 Hz 0.1 0 - -
{04} LAI PCT OUTPUT 0 PCT 0.1 0 - -
{05} LAI SPEED 0 RPM 1 0 - -
{06} LAI CURRENT 0 A 0.1 - -
{07} LAI TORQUE 0 PCT 0.1 -200 - -
{08} LAI POWER 0
(0)
HP
(KW)
0.134
0.1
0
0
--
{09} LAI DRIVE TEMP 77
(25)
° F
(
° C)
0.18
(0.1)
32
0
--
{10} LAI DRIVE KWH 0 KWH 1 - -
{11} LAI DRIVE MWH 0 MWH 1 - -
{12} LAI RUN TIME 0 HRS 1 - -
{13} LAI DC BUS VOLT 0 V 1 - -
{14} LAI OUTPUT VOLT 0 V 1 - -
{15} LAI PRC PID FBCK 0 PCT 0.1 - -
{16} LAI PRC PID DEV 0 PCT 0.1 - -
{17} LAI MOTOR TEMP 77(25)
° F (° C) 1.8 (1) 32 0 - -
{18} LAI MREV
COUNTER
0MREV10 - -
20 LAO OVRD TIME 1 hrs 1 0 - -
{21} LDI FWD.REV FWD - 1 0 REV FWD
{22} LDO CMD FWD.REV FWD - 1 0 REV FWD
{23} LDI STOP.RUN STOP - 1 0 RUN STOP
{24} LDO CMD STP.STRT STOP - 1 0 RUN STOP
{25} LDI EXT1.2 ACT EXT1 - 1 0 EXT2 EXT1
{26} LDO EXT1.2 CMD EXT1 - 1 0 EXT2 EXT1
{27} LDI DRIVE READY NOTRDY - 1 0 READY NOTRDY
{28} LDI AT SETPOINT NO - 1 0 YES NO
{29} LDO DAY.NIGHT DAY - 1 0 NIGHT DAY
30 LAO CURRENT LIM 0 A 0.1 0 - -
31 LAO ACCEL TIME 1 300 sec 0.1 0 - -
32 LAO DECEL TIME 1 300 sec 0.1 0 - -
{33} LDI HANDAUTO
ACT
AUTO - 1 0 HAND AUTO
