FLN Protocol Technical Data
{34} LDI ENA.DIS ACT DISABL - 1 0 ENABLE DISABL
{35} LDO ENA.DIS CMD DISABL - 1 0 ENABLE DISABL
{36} LDI FLN LOC ACT AUTO - 1 0 FLN AUTO
{37} LDI CTL SRC NO - 1 0 YES NO
{38} LDI FLN REF1 SRC NO - 1 0 YES NO
{39} LDI FLN REF2 SRC NO - 1 0 YES NO
{40} LDO RO 1
COMMAND
OFF - 1 0 ON OFF
{41} LDO RO 2
COMMAND
OFF - 1 0 ON OFF
{42} LDO RO 3
COMMAND
OFF - 1 0 ON OFF
{43} LDO RO 4
COMMAND
OFF - 1 0 ON OFF
{44} LDO RO 5
COMMAND
OFF - 1 0 ON OFF
{45} LDO RO 6
COMMAND
OFF - 1 0 ON OFF
{46} LAO AO 1
COMMAND
PCT PCT 0.1 0 - -
{47} LAO AO 2
COMMAND
PCT PCT 0.1 0 - -
48 LDO RST RUN TIME NO - 1 0 RESET NO
49 LDO RESET KWH NO - 1 0 RESET NO
50 LAO PRC PID GAIN 10 PCT 0.1 0 - -
51 LAO PRC PID ITIM 600 SEC 0.1 0 - -
52 LAO PRC PID DTIM 0 SEC 0.1 0 - -
53 LAO PRC PID DFIL 10 SEC 0.1 0 - -
54 LDO PRC PID SEL SET1 - 1 0 SET2 SET1
55 LAO EXT PID GAIN 10 PCT 0.1 0 - -
56 LAO EXT PID ITIM 600 SEC 0.1 0 - -
57 LAO EXT PID DTIM 0 SEC 0.1 0 - -
58 LAO EXT PID DFIL 10 SEC 0.1 0 - -
59 LDO LOCK PANEL UNLOCK - 1 0 LOCK UNLOCK
{60} LAO INPUT REF1 0 PCT 0.1 0 - -
{61} LAO INPUT REF2 0 PCT 0.1 0 - -
{62} LAO EXT PID STPT 0 PCT 0.1 0 - -
{63} LAI EXT PID FBCK 0 PCT 0.1 0 - -
{64} LAI EXT PID DEV 0 PCT 0.1 0 - -
FLN Point Database
Point
Subpoint Name
Factory
Default
Engr.
Units
Slope Intercept
On Text Off Text
# Type (SI Units)
