FLN Protocol Technical Data
21 FWD.REV ACT Indicates the rotational direction of the motor, regardless of
control source (1 = REV, 0 = FWD).
22 FWD.REV CMD Commanded by FLN to change the rotational direction of the
drive.
• Parameter 1001 must be set to COMM for FLN to control
the direction of the motor by EXT1.
• Parameter 1002 must be set to COMM for FLN to control
the direction of the motor by EXT2.
23 RUN.STOP ACT Indicates the drive's run status, regardless of control source
(1 = RUN, 0 = STOP).
24 RUN.STOP CMD Commanded by FLN to start the drive.
• Parameter 1001 must be set to COMM for FLN to control
the run state of the drive by EXT1.
• Parameter 1002 must be set to COMM for FLN to have
this control.
25 EXT1.2 ACT Indicates whether External 1 or External 2 is the active
control source (1 = EXT2, 0 = EXT1).
26 EXT1.2 CMD Commanded by FLN to select External 1 or External 2 as the
active control source (1 = EXT2, 0 = EXT1).
Parameter 1102 must be set to COMM for FLN to have this
control.
27 DRIVE READY Indicates the drive is ready to accept a run command
(1 = READY, 0 = NOTRDY).
28 AT SETPOINT Indicates the drive has reached its commanded setpoint
(1 = YES, 0 = NO)
29 DAY.NIGHT 1 of the 5 mandatory FLN points required for compatibility
with Siemens control systems. It has no functionality in the
drive application.
None
30 CURRENT LIM Sets the output current limit of the drive. 2003
31 ACCEL TIME 1 Sets the acceleration time for Ramp 1. 2202
32 DECEL TIME 1 Sets the deceleration time for Ramp 1. 2203
33 HANDAUTO
ACT
Indicates whether the drive is in Hand or Auto control
(1 = HAND, 0 = AUTO).
34 ENA.DIS ACT Indicates the status of the Run Enable command, regardless
of its source (1 = ENABLE, 0 = DISABL).
35 ENA.DIS CMD Commanded by FLN to assert the Run Enable command
(1 = ENABLE, 0 = DISABL).
Parameter 1601 must be set to COMM for FLN to have this
control.
36 FLN LOC ACT Indicates if the drive has been placed in “FLN LOCAL” mode
by commanding either point 68 (FLN LOC CTL) or point 69
(FLN LOC REF). Commanding either of these points to FLN
(1) “steals” control from its normal source and places in under
FLN control.
Note that the HAND mode of the panel has priority over FLN
local control.
FLN Detailed Point Descriptions
Point Description
Drive
Parameter
