3. Easy commissioning

3.1 Commissioning menu (submenu Q2 of Quick Menu)

The commissioning menu has a set of 11 parameters that are necessary during typical commissioning. These parameters are arranged logically

instead of by number. Note: always enter the parameters in the order shown. To access the commissioning menu, press the [Quick Menu] button,

select „Q2 commissioning menu“, and conﬁrm with [OK]. Press the [Status] button to return to normal view.

Par. Description Setting

0-01 Language English [0] or set to local language

1-20 Motor power [kW] According to motor nameplate data

1-22 Motor voltage [V] According to motor nameplate data

1-23 Motor frequency [Hz] According to motor nameplate data

1-24 Motor current [A] According to motor nameplate data

1-25 Rated motor speed [rpm] According to motor nameplate data

3-41 Ramp-up time 1 Set ramp-up time (acceleration time up to rated motor speed)

3-42 Ramp-down time 1 Set ramp-down time (deceleration time from rated speed to zero RPM)

4-12 Min. speed [RPM] Set desired minimum speed

4-14 Max. speed [RPM] Set desired maximum speed

1-29 Automatic Motor Adaptation (AMA) AMA is worthwhile if motor operation is unsatisfactory or additional

optimisation is desired.

See the description of AMA in the product guide.
