Philips FC6842 Triathlon [11/170] Dry vacuuming

9 Remove the micro filter (specific types only) (fig. 20).

Note that the micro filter will lose its electrostatic properties if exposed to excessive air humidity.

Now the appliance is ready for vacuuming liquids. If you want to shampoo floors, follow the rest of

the instructions below to prepare the appliance for shampooing floors.

10 Fill the shampoo reservoir with cold water (fig. 21).

11 Add one measuring cup of cleaning liquid to the full reservoir (fig. 22).

12 Attach the shampoo reservoir to the appliance (fig. 23).

13 Attach the short shampoo hose to the connector on the vacuum cleaner by inserting the

shampoo hose into the connector (1) and turning it anticlockwise (2) (fig. 24).

14 Attach the long shampoo hose to the shampoo trigger (fig. 25).

15 Fix the shampoo trigger to the handgrip of the suction hose (fig. 26).

16 Firmly insert the end of the long shampoo hose into the connector on the vacuum cleaner

(you will hear a click) (fig. 27).

◗ To release the shampoo hose, push the ring towards the appliance (fig. 28).

17 Attach the long shampoo hose to the suction hose and suction tubes by means of the clips

(fig. 29).

18 Attach the double injection nozzle (fig. 30).

The appliance is now ready for shampooing soft floors, such as carpets and rugs.

Using the appliance

Switching the appliance on

1 Pull the mains cord out of the appliance and insert the mains plug into the wall socket (fig. 31).

2 Switch the appliance on (fig. 32).

Dry vacuuming

Convertible nozzle (specific types only)

The convertible nozzle is active over its full width and even vacuums from its sides. It is therefore

very suitable for vacuuming along skirting boards, furniture and thresholds.

◗ The convertible nozzle can be used for vacuuming hard and soft floors (fig. 33).

- Brush strip out for cleaning hard floors (wooden, ceramic, stone and synthetic floors)

- Brush strip in for cleaning soft floors (carpets and rugs)

Reach & Clean nozzle (specific types only)

◗ The Reach & Clean nozzle can be used on either carpets or hard floors.The nozzle can be

put in 4 different positions, allowing you to also vacuum clean hard-to-reach places in an easy

way.The nozzle can be turned 360 degrees clockwise as well as anticlockwise.When the

nozzle is positioned lengthwise, the suction power is concentrated at the front side of the

nozzle (fig. 34).

◗ To adjust the nozzle to the type of floor and the area to be cleaned, put your foot on one of

the indicated spots on the nozzle and then turn the tube until the nozzle is in the required

position (fig. 35).

◗ With the nozzle positioned breadthwise and the brush strip folded out, you can clean large

hard floor areas.Turn the tube until the brush strip pops out of the nozzle housing and the

nozzle is positioned breadthwise (fig. 36).

ENGLISH 11
