MEASUREMENT FOUNDATION

ProDigit 30

Pitch (Fig.7)

The digital laser level can be used to measure the pitch of a roof. It measures the pitch in inches

of rise per foot of run. Push the conversion button to change angle to pitch. The pitch will be

read as inches per foot in 1/8-in. increments, with a + or a - sign to indicate if the pitch is above

or below the desired measurement.

Angle (Fig.8)

The digital laser level measures any angle in degrees with up to 0.1° accuracy, at level or plumb

position, the accuracy will be up to 0.05°. This can be used to nd the necessary angle for many

surfaces, and when the conversion button is pushed to display angle, will tell you the angle and

which way it is off of true level. If the beeper button is turned on, the level will beep at 0.00°

angle.

Slope (Fig.9)

The digital laser level measures the slope of a surface in percent. This is useful when laying pipe

for proper drainage. When the conversion button is in the slope mode, it will display the surface

being measured in percent, with exact level at 0.00%. If the beeper button is turned on, the level

will beep at 0.00%.
