![Danfoss MCD 201-075-T6-xxx [5/24] N general technical data](/views2/1563280/page5/bg5.png)
MCD 200 Design Guide
MCD 200 Series
Overview
■ General Technical Data
Mains Supply (L1, L2, L3):
MCD 200-xxx-T4-xxx .............................................................................. 3 x 200 VAC ~ 440 VAC (+10% / - 15%)
MCD 200-xxx-T6-xxx .............................................................................. 3 x 200 VAC ~ 575 VAC (+10% / - 15%)
Supply frequency (at start) ................................................................................................................ 45 Hz - 66 Hz
Control Supply (A1, A2, A3):
MCD 200-xxx-xx-CV1 .......................................................................................................... 24 VAC/VDC (± 20%)
MCD 200- x xx-xx-CV3 .......................................... 110-240 VAC (+10% / - 15%) or 380-440 VAC (+10% / - 15%)
Control Inputs
Start Terminal N1 .................................................................................................... Normally Open, 300 VA C max.
Stop Terminal N2 .................................................................................................. Normally Closed, 300 VAC max.
Relay Outputs
Main Contactor (Terminals 13 & 14) ................................................................................................ Normally Open
Main Contactor (Terminals 13 & 14) .................................................... 6 A, 30 VDC resistive / 2 A, 400 VA C, AC11
Programmable Relay (Terminals 23 & 24) ........................................................................................ Normally Open
Programmable Relay (Terminals 23 & 24) ............................................ 6 A, 30 VDC resistive / 2 A, 400 VAC, AC11
Environmental
Degree of protection MCD 200-007 to MCD 200-055 .................................................................................... IP20
Degree of protection MCD 200-075 to MCD 200-110 .................................................................................... IP00
Operating Temperatures ............................................................................................................... -10 °C / + 60 °C
Humidity ................................................................................................................... 5% to 95% Relative Humidity
Pollution Degree ........................................................................................................................ Pollution Degree 3
Vibration ................................................................................................................... IEC 60068 Test Fc Sinusoida l
Vibration ...................................................................................................... 4 Hz - 13.2 Hz: ± 1 mm displacement
Vibration ........................................................................................................................ 13.2 Hz - 100 Hz: ± 0.7 g
EMC E mission
Equipment class (EMC) ............................................................................................................................... Class A
Conducted radio frequency emission ................................................................ 0.15 MHz - 0.5 MHz: < 90 dB (µV)
Conducted radio frequency emission ..................................................................... 0.5 MHz - 5 MHz: < 76 dB (µV)
Conducted radio frequency emission .................................................................... 5 MHz - 30 MHz: 80-60 dB (µV)
Radiated radio frequency emission ................................................................. 30 MHz - 230 MHz: < 3 0 dB (µV/m)
Radiated radio frequency emission ............................................................. 230 MHz - 1000 MHz: < 37 dB (µV/m)
This product has been designed for Class A equipment. U se of the product in domestic environments may
cause radio interference, in which case the user m ay be required to employ additional mitigation methods.
EMC Immunity
Electrostatic disch arge .......................................................................... 4 kV contact discharge, 8 kV air discharge
Radio frequency electromagnetic field ............................................................. 0.15 MHz - 1000 MHz: 140 dB (µV)
Rated impulse withstand voltage (Fast transients 5/50 ns) ............................................................ 2 kV line to earth
Rated insulation voltage (Surges 1.2/50 µs – 8/20 ms) ........................................ 2 kV line to earth, 1 kV line to line
Voltage dip and short tim e interruption ........................................... ...................... 100 m s (at 40% nominal voltage)
Short Circuit
Rated short-circuit current MC D 200-007 to MCD 200-037 ............................................................................ 5 kA
Rated short-circuit current MC D 200-045 to MCD 200-110 .......................................................................... 10 kA
MG.17.C2.02 - VLT is a registered Danfoss trademark
