MCD 200 Design Guide
Heat Dissipation
During Start ................................................................................................................................. 3 watts / ampere
During Run .............................................................................................................................................. < 4 watts
Standards Approvals
C ................................................................................................................................................. IEC 60947-4-2
UL / C-UL .................................................................................................................................................... UL508
CE .................................................................................................................................................. IEC 60947-4-2
CCC ................................................................................................................................................... GB 14048.6
