Operation and Display

C220/C420 General Flux Vector Control Inverter User Manual

3.1.2 Digital display zone:

Five digits LED display is able to show setup frequency ,output

frequency ,various monitoring data and alarm code. According to function code

F7-29/F7-30 , the user can freely set the data in need ,all the details are shown as

function code F7-29/F7-30.

3.1.3 Key Button Description

Tab.1 Keyboard function table

Button

Name

Function

PRG/ESC Program/ Exit entry or exit ,return to primary menu

ENTER

entry into the menu interface ,confirm the setup

parameters

increase (+) Increase in the data or function code

decrease (-) Decrease in the data or function code

》 shift key

select the displayed parameters in turn on the

stop display interface and running display

interface ,and select the modification digit of

parameters when modifying parameters.

RUN Run key

used in running operation under keyboard

control mode

STOP/RESET STOP/RESET

In the status of running ,pressing it can stop the

running operation; in f

ault alarm ,can reset

operation, this button characteristic is limited
