Operation and Display

C220/C420 General Flux Vector Control Inverter User Manual

.00 F0

-00

-02

F2-

PRG

ENTER

PRG

050.

00 050.

00020.

Fig.7 Example of parameter editing operation

Caution: in level 3 menu, if the parameter has no flashing bit ,it indicates that the

function code cannot be modified. The possible reasons include:

1）the function code is an unchangeable parameter such as actual detection

parameter, running record parameter, etc.

2）the function code is an unchangeable in running, and can be modified in

stop

3.3 Method of Viewing Status Parameters

In stop or running, it can display multiple status parameters, and select

whether to display the parameter through the function codes F7-29(Led running

parameters) and F7-30 (stop parameter) in accordance with binary bits. For the

meaning of binary bits, refer to Chapter 6 F7-29 and F7-30

In status of stop, there are seven stop status parameters for selection, namely:

setup frequency ,bus voltage, DI input status, DO output status, analog input A11

voltage, PLC running step, the displaying of the selected parameters can be switched

by pressing shift key in sequence( displaying of parameters are converted into binary

system by F7-30)

In running , there are thirteen running parameters displayed , five parameters

are displayed for running frequency ,setup frequency ,bus voltage, output voltage

and output current ,other eight parameters for output power ,DI input status, DO

output status, analog input A11 voltage ,analog input A12 voltage ,PID setup, PID

feedback and PLC, These parameters are displayed in accordance with the selection

of F7-29 (converted into binary system).The displaying of the selected parameters

can be switched by the button in sequence
