Basic Reference Guide
C220/C420 General Flux Vector Control Inverter
2.1 Description of main circuit terminals of single-phase inverter:
Terminals Name Description
L、N
Single-phase power
input
terminal
Connect to the AC single-
phase 220V
power supply
(+)、(-)
Negative and
positive
terminals of DC
bus
Shared DC bus input point
(+)、PB
Connecting terminal
of
braking resistor
Connect to the braking resistor
U、V、W
Output terminal of
inverter
Connect to the three-phase motor
Grounding terminal Grounding terminal
2.2 Description of main circuit terminals of three-phase inverter:
Terminals Name Description
R、S、T
Three-phase power input
terminal
Connect to the AC three-phase
380V power supply
(+)、(-)
Negative and positive
terminals of DC bus
Shared DC bus input point
(+)、PB
Connecting terminal for
brake resistor.
Connection points for the brake
U、V、W
Output terminal of inverter Connect to three-phase motor
Grounding terminal Grounding terminal
