Chapter 6 Control Terminals|C200 Series
6-6
Sink Mod
e
Internal power supply(+24Vdc
)
DCM
+24V
COM
Vcc
A/B
GND
AB/
MI7/MI8
0V mode encoder C200 external terminal
GND+24V
external
power supply
5. Since MI1~MI8 shares the same COM, therefore when using a PG card, MI~MI6 can only be
applied at SINK MODE.
