Chapter 7 Optional Accessories |C200 Series
7-20
CANopen communication cable
Model #: TAP-CB03, TAP-CB04
L
Title Part No.
mm inch
1 TAP-CB03
500 ± 10 19 ± 0.4
2 TAP-CB04
1000± 10 39 ± 0.4
Dimensions
Unit: mm [inch]
