Verto 50G390 [10/56] Operation settings
![Verto 50G390 [10/56] Operation settings](/views2/1569901/page10/bga.png)
10
DEPTH GAUGE ROD INSTALLATION
Depth gauge (9) serves to limit the depth of drill penetration of material
• Loosen the wheel lock, which blocks collar of the additional handle (8).
• Slide depth gauge rod (9) into the hole in the additional handle collar.
• Set desired drill depth.
• Fix by tightening the wheel lock.
INSTALLATION AND REPLACEMENT OF WORKING TOOLS
Hammer drill is designed to operate with working tools with SDS-Plus
shanks.
Prior to starting operation clean the hammer drill and working tools.
Use grease and apply thin layer onto shank of the working tool. It will
improve tool durability.
Disconnect the power tool from power supply.
• Put the hammer against work bench.
• Hold the xing sleeve (2) of the SDS chuck (1) and pull it to the back,
overcoming the spring resistance .
• Insert working tool s hank into the chuck and slide it to mechanical
stop (it may be necessary to turn the working tool so it can reach
appropriate position) (g. A).
• Release the xing sleeve (2), it will nally x the tool.
• Working tool is properly seated if it cannot be removed without
pulling o the xing sleeve.
• If the sleeve does not return to its default position, remove the
working tool and repeat the whole operation.
High eciency of the hammer drill operation can be achieved by
using sharp and undamaged working tools.
DEINSTALLATION OF WORKING TOOL
Just after the operation is nished, the working tool may be hot.
Avoid direct contact and use appropriate protective gloves. Clean
the working tool after removal.
Disconnect the power tool from power supply.
• Pull the xing sleeve (2) to the back and hold.
• Remove the working tool with your second hand by pulling it to
the front.
OVERLOAD CLUTCH
Hammer drill is equipped with factory set overload clutch. Spindle of
the hammer drill stops immediately after working tool jams, which
might overload the power tool.
USE OF ANTI-DUST COVER
Anti-dust cover is round, rubber casting of appropriate shape. It is
placed on the drill to catch dust when drilling in ceiling for example.
Put the cover on a drill, bring the drill close to the surface and move the
cover along the drill until it reaches surface of the processed material. As
the tool gets deeper into the material, the cover slides on the drill and
catches the dust produced. Empty the cover from time to time.
Always use glasses or anti-splinter goggles, especially when
drilling a hole above your head.
OPERATION / SETTINGS
SWITCHING ON / SWITCHING OFF
The mains voltage must match the voltage on the rating plate of
the hammer drill.
Switching on – press the switch button (5) and hold in this position
(g. B).
Switching o – release pressure on the switch (5).
OPERATION MODE SWITCHES
Hammer drill features two switches of the working mode: impact
mode switch (6) (g. D) and drilling mode switch (3) (g. E).
Depending on its settings, a drilling only, impact drilling or chiselling
is possible. Impact drilling and chiselling require to slightly press the
hammer drill. Excessive pressure would cause excessive motor load.
Check technical condition of the working tools regularly. Sharpen or
replace working tools when needed.
Appropriate setting of switches for each of the functions is shown on (g. F).
Drilling without impact – pos. I
Impact drilling – pos. II
Chiselling – pos. III
Press the lock button (g. G) prior to change of position of the
drilling mode switch (3). Do not try to change position of the
working mode switches when the hammer drill motor is operating.
Such action may cause serious damage of the hammer drill.
DRILLING HOLES
• When drilling a hole with large diameter, it is recommended to
drill smaller hole and then ream it to desired diameter. It prevents
overloading the hammer drill.
• When drilling deep holes drill gradually to smaller depths, then slide
the drill out of the hole to remove chips and dust.
• If a drill jam occurs during drilling, the overload clutch will work.
Turn o the hammer drill immediately to prevent its damage.
Remove jammed drill from the hole.
• Keep the hammer drill in the axis of the hole. Keeping the drill
perpendicular to the surface of the processed material is highly desirable.
If a drill is not kept perpendicular to the surface during operation, it may
get jammed or broken in the hole and injure the user.
Long lasting drilling at low rotational speed of the spindle may
cause motor overheating. Make periodic breaks in operation. Do
not cover holes for motor ventilation in the hammer drill body.
IMPACT DRILLING
• Choose appropriate mode of operation, impact drilling in this case.
• Insert appropriate drill with SDS-PLUS shank into the chuck (1).
• To get the best results use high quality drills with sintered carbide
inserts.
• Press the drill against processed material.
• Switch on the hammer drill, the hammer mechanism should
operate smoothly and the tool should not bounce on the processed
material surface.
OPERATION AND MAINTENANCE
Unplug the power cord from the mains socket before commencing any
activities related to installation, adjustment, repair or maintenance.
