1 CONSTRUCTIVE FEATURES
WH high wall mounted fan coils, proposed in three models with cooling
capacities ranging from 2 to 4.28 kW, make the ideal indoor unit for air
conditioning systems in public buildings, shops and hotels.
Coupled with Galletti water chillers and heat pumps, they provide an
environmentally friendly alternative to direct expansion systems.
WH fan coils are hallmarked by the quality of their components and their
versatility of use:
> High efficiency heat exchanger made with copper piping and
aluminium fins, low pressure drop on the water side.
The heat exchanger comes complete with manual air valves and
hoses for connection to the system or to the rear valve-fitted panel
(optional accessory).
> Extremely quiet tangential fan connected to a 3-speed electric motor
with a low number of revolutions.
> Motorised air outlet buffle for adjusting the direction of the airflow
from the fan coil.
> The high quality plastics used allow operation with hot water up to
a temperature of 75°.
> Microprocessor controlled operation with control of air intake
temperature and that of the water inside the heat exchanger that
regulates the heating function according to the temperature of the
water (from 38°C to 75°C).
The auto restart function makes it possible
to automatically restore unit management
after blackouts.
> Infra-red remote control that when
combined with the microprocessor control
allows simple, versatile management of
the fan coil:
- temperature setting
- manual or automatic fan speed
selection
- manual or automatic operating
mode selection
- cooling
- ventilation
- heating
- automatic air outlet buffle
oscillation with position control
- night mode setting
- Automatic 24-hour on-off timer
- Clock
- LCD for displaying all fan coil functions
The remote control comes packed separately, complete with wall bracket.
> Pilot lights on the front panel indicate unit operation.
> Air filter easily extractable for cleaning.
2 AVAILABLE ACCESSORIES
BP
Rear panel complete that allow
the installation of the 3way
valve
VK
3-way ON/OFF valve for even
more accurate regulation of
room temperature.
Electrothermal ON-OFF valve
motor, suitable for 230 volt
power supply and connection
to the unit's terminal board.
DECLARATION OF CONFORMITY
Galletti S.p.A. hereby declares, under its sole responsibility, that
WH high wall fan coil units series have been designed, built and
tested in conformity with the specifications of European Directives:
· 98/37/CE (Machinery Directive)
· 73/23/CEE (Low Voltage Directive)
· 89/336/CEE (Directive on Electromagnetic Compatibility)
· 97/23 CE (PED)
Bentivoglio, 29/03/2004
Galletti S.p.A.
Luigi Galletti
OPERATING LIMITS
> thermal fluid: water
> Water temperature: from 7°C to 75°C
> maximum operating temperature:10 bar
> air temperature: from 5°C to 35°C
> air temperature with moist bulb: max 24°C
> power supply: +/- 10%
