Galletti WH10 [5/8] Heating capacity
![Galletti WH10 [5/8] Heating capacity](/views2/1572244/page5/bg5.png)
5
SY66000120 - 03
All copying, even partial, of this manual is strictly forbidden
WH
7 HEATING CAPACITY
Legend:
Dpw Pressure drop on water side
PT Heating capacity
Qw Water flow rate
Tbs
1
Inlet air temperature dry bulb
Tw
1
Inlet water temperature
Tw
2
Outlet water temperature
Vr Fan speed:
3 high
2 medium
1 low
Tbs
1
Tw
1
/ Tw
2
Vr PT Qw
pw
PT Qw
pw
PT Qw
pw
Wl/hkPaWl/hkPaWl/hkPa
3 2640 459 16 4130 361 10 5340 468 15
2 2380 413 13 3720 326 8 4820 423 13
1 2250 392 12 3530 309 8 4570 401 12
3 3850 669 19 6050 529 12 7820 685 18
2 3490 607 16 5500 480 10 7090 622 15
1 3220 560 14 5070 443 9 6550 575 13
3 4920 856 20 7720 674 12 9960 873 19
2 4290 746 16 6730 588 10 8670 760 15
1 3960 688 14 6220 543 8 7990 701 13
Tbs
1
Tw
1
/ Tw
2
Vr PT Qw
pw
PT Qw
pw
PT Qw
pw
Wl/hkPaWl/hkPaWl/hkPa
3 2390 415 13 3870 338 9 5080 446 14
2 2150 374 11 3490 305 7 4590 402 12
1 2040 355 10 3310 289 7 4350 382 11
3 3480 605 16 5670 495 10 7430 652 16
2 3160 549 13 5140 450 9 6750 592 14
1 2910 507 11 4750 415 8 6230 547 12
3 4470 777 17 7250 633 11 9480 831 17
2 3890 677 13 6320 552 9 8250 724 14
1 3590 624 11 5830 510 8 7610 668 12
WH 10
WH 20
WH 30
22°C
45 / 40°C 60°C / 50°C 70°C / 60°C
WH 10
WH 20
WH 30
20°C
70°C / 60°C60°C / 50°C45 / 40°C
