3
SY66000120 - 03
All copying, even partial, of this manual is strictly forbidden
WH
3 REMOTE CONTROL FUNCTION
REMOTE CONTROL FUNCTIONS
- If the room temperature is lower than the setting temperature, the
heating mode is activated. The motor driven valve is triggered. The
internal fan works at the set speed.
- If the room temperature is equal to the setting temperature + 0.5°C,
the heating mode is stopped. The motor driven valve and the internal
fan are disconnected.
- The setting temperature range is 15° - 30°C.The internal fan speed can
be set on Min, Med, Max and Auto.
- The motor driven valve will be activated/deactivated after a delay time of
30 sec
- If the water temperature is equal to 38°C, the motor driven valve is
activated and the internal fan is deactivated.
- If the water temperature is >38°C the motor driven valve is activated. The
internal fan will continue working at the set speed.
- If the water temperature is >75°C the motor driven valve is deactivated.
The internal fan will continue working at the set speed.
COOLING
- If the room temperature is higher than the set temperature, the cooling
mode is activated. The motor driven valve is activated. The internal fan
works at the set speed.
- If the room temperature is equal to the setting temperature -0.5°C, the
cooling mode is stopped. The motor driven valve is deactivated. The
internal fan works at the set speed.
- The setting temperature range is 15° - 30°C.
- The internal fan speed can be set on Min, Med, Max and Auto.
- The motor driven valve will be activated/deactivated after a delay time of
30 sec.
- If the water temperature is equal to or lower than 2°C, the motor driven
valve is deactivated and the internal fan continues working at the set
speed.
TIMER
- The switch off timer can be set only when the system is ON.
- The switch on timer can be set only when the system is OFF.
- The maximum setting time is 24 hours.
- Switching the unit on/off will cancel the timer mode.
4 RATED TECHNICAL DATA
- Cooling mode: water temperature 7/12°C, air temperature 27°C dry bulb, 19°C wet bulb
- Heating mode: water temperature 70-60°C, air temperature 20°C
- Sound pressure calculated for 1 meter distance, under the unit
Fan speed
WH10 WH20
WH30
Total cooling capacity
High
kW 2,27 3,06 4,28
Sensible cooling capacity
High kW 1,72 2,41 3,15
Water flow
l/h 389 524 734
Water pressure drop
kPa151318
Heating capacity
High kW 5,34 7,87 9,96
Water flow
l/h 468 685 873
Water pressure drop
kPa151819
Water connection
"1/21/21/2
Drain connection
mm 22 22 22
Water content
dm
3
0,5 1,1 1,8
High
m
3
/h
415 515 750
Med
m
3
/h
360 460 630
Low
m
3
/h
335 420 570
Power supply
V / f / Hz 230 /1 / 50 230 /1 / 50 230 /1 / 50
Current absorption
High A 0,15 0,17 0,24
Power input
W343951
High dB(A)545460
Med dB(A) 50 51 55
Low dB(A) 48 49 51
High dB(A)464652
Med dB(A) 42 43 47
Low dB(A) 40 41 43
Overall dimension: height
mm 276 320 330
Overall dimension: lenght
mm 870 1020 1160
Overall dimension: depth
mm 183 185 213
Approx. weight
kg 12 15 18
Sound power level
Sound pressure level
Air flow
