LCE
RG66004766_rev.05
47
Cooling mode: outdoor air temperature 35°C, water temperature 12°C / 7°C
Heating mode: outdoor air temperature 7°C dry bulb and 6.2°C wet bulb, water temperature 40°C/45°C
Sound power measured according to standards ISO 3741 - ISO 3744 and EN 29614-1
Sound pressure measured at a distance of 10 m and a height of 1.5 m above the ground in a clear field.
Approx, capacity (kW) 170 190 210 240 270
290 320 360
Efficiency Pack 1241244 4 4 44
444
LCE…HS 141 142 144 161 162 164 174 194 214 244 274 294 324 364
Power supply V-ph-Hz
Cooling capacity kW 138,3 137,7 140,3 155,1 154,7 153,4 161,8 186,9 209,0 237,0 271,9 296,2 214,3 353,4
Total power input in cooling mode kW 48,3 52,6 47,7 58,7 64,0 56,1 61,9 77,3 91,1 101,6 113,9 123,8 131,8 138,1
Rated current input A 82,5 89,4 81,6 99,2 107,7 95,0 104,2 128,8 151,0 167,8 189,2 205,1 218,0 227,9
EER 2,87 2,62 2,94 2,64 2,42 2,74 2,61 2,42 2,29 2,33 2,39 2,39 2,38 2,56
ESEER 3,93 4,01 4,1 3,61 3,79 3,75 4,04 3,84 3,84 3,89 3,94 3,91 4,05 4,18
Heating capacity kW 152,4 153,1 149,3 179,8 180 175,7 188 211,9 235,8 273,5 306,7 330,5 351,2 425,8
Total power input in heating mode kW 46,3 41,2 45,8 55,6 50 55 50,4 59,7 67,9 80,1 88,5 97 105,2 124,3
Rated current input A 79,27 71,12 78,44 94,19 85,29 93,2 85,69 135,3 113,78 133,39 148,48 162,05 175,18 205,88
COP 3,29 3,72 3,26 3,24 3,6 3,2 3,73 3,5 3,47 3,41 3,47 3,41 3,34 3,43
Maximum current input A 131 131 129 137 144 150 136 155 173 196 224 237 251 300
Starting current A 330 330 245 389 396 266 252 310 330 380 403 468 476 497
No, of scroll compressors / circuits 2 / 2 2 / 1 4 / 2 2 / 2 2 / 1 4 / 2 4 / 2 4 / 2 4 / 2 4 / 2 4 / 2 4 / 2 4 / 2 4 / 2
No, of axial fans 8888886 6 6 68888
Air flow rate m
3
/h 39890 39890 39890 39890 39890 39890 67672 67672 67672 75478 103511 97902 97902 97902
Water flow rate (cooling) l/h 23805 23805 24143 26660 26660 26378 27864 32095 35948 40747 46716 50827 53990 60257
Pressure drop, water side (cooling) kPa 484950424242 4649 50 5341495541
Available head, standard pump (cooling) kPa 150 150 147 147 147 148 155 133 147 171 170 152 137 134
Buffer tank dm
3
340 340 340 340 340 340 600 600 600 600 600 600 600 600
Expansion tank dm
3
12 12 12 12 12 12 24 24 24 24 24 24 24 24
Plumbing connections 2 1/2 2 1/2 2 1/2 2 1/2 2 1/2 2 1/2 3 3 3 4 4 4 4 4
Height mm 1735 1735 1679 1735 1735 1679 1847 1847 1847 2247 2330 2330 2330 2330
Length mm 3190 3190 3540 3190 3190 3540 3538 3538 3538 3538 4206 4206 4206 4206
Depth mm 1183 1183 1183 1183 1183 1183 1653 1653 1653 1653 1653 1653 1653 1653
Sound power level dB(A) 82,0 86,0 82,0 82,0 86,0 82,0 87,0 87,0 87,0 87,0 88,0 88,0 88,0 84,0
Sound pressure level dB(A) 54,0 58,0 54,0 54,0 58,0 54,0 59,0 59,0 59,0 59,0 60,0 60,0 60,0 56,0
Base unit operating weight kg 1055 1055 1070 1085 1085 1220 1440 1460 1470 1620 1880 1912 1947 1947
Unit with pump and full tank operating weight kg 1626 1626 1661 1656 1656 1811 2208 2276 2286 2469 2894 2926 2961 2961
140 160
400-3-50
Rated technical data of LCE heat pumps, STANDARD version
