LCE
RG66004766_rev.05
50
Cooling mode: outdoor air temperature 35°C, water temperature 12°C / 7°C
Heating mode: outdoor air temperature 7°C dry bulb and 6.2°C wet bulb, water temperature 40°C/45°C
Sound power measured according to standards ISO 3741 - ISO 3744 and EN 29614-1
Sound pressure measured at a distance of 10 m and a height of 1.5 m above the ground in a clear field.
Approx, capacity (kW) 45 50 60 70 80 120
Efficiency Pack 2222212 4 1 24124
LCE…HQ 042 052 062 072 082 091 092 094 101 102 104 121 122 124
Power supply V-ph-Hz
Cooling capacity kW 48 52 64 70 77 93 93 94 104 104 102 124 124 126
Total power input in cooling mode kW 16,2 20,2 24 27 30,9 32 35 32,3 38,4 38,7 37,1 45 47,1 45,1
Rated current input A 27,68 34,16 41,08 45,85 52,03 54,74 59,57 55,25 64,92 65,39 62,84 73,45 76,84 73,59
EER 2,96 2,58 2,65 2,59 2,51 2,9 2,65 2,92 2,7 2,68 2,76 2,75 2,62 2,79
ESEER 4,06 3,96 3,89 3,93 3,78 3,45 3,88 3,9 3,4 3,75 3,85 3,88 4,15 4,09
Heating capacity kW 53,3 60,6 70,7 78,5 86,4 104,7 104,5 102,7 118 117,3 115,6 135,5 123 133,3
Total power input in heating mode kW 16 18 20 22 26 31 30 30 35 35 35 42 39 42
Rated current input A 26,58 30,47 33,98 38,39 43,53 52,32 51,68 51,99 60,19 59,17 59,51 69,09 64,43 68,44
COP 3,44 3,38 3,61 3,51 3,38 3,43 3,47 3,39 3,33 3,37 3,3 3,21 3,13 3,18
Maximum current input A 41 44 51 55 66 77 77 81 86 86 87 99 99 100
Starting current A 159 162 185 183 191 246 246 194 254 254 198 299 299 225
No, of scroll compressors / circuits 2 / 1 2 / 1 2 / 1 2 / 1 2 / 1 2 / 2 2 / 1 4 / 2 2 / 2 2 / 1 4 / 2 2 / 2 2 / 1 4 / 2
No, of axial fans 4466688 8 8 88666
Air flow rate m
3
/h 15398 15398 21955 21955 21955 29393 29393 29393 29393 29393 29393 35930 35930 35930
Water flow rate (cooling) l/h 8261 8983 10956 12027 13313 15986 15986 16213 17778 17778 17582 21259 21259 21623
Pressure drop, water side (cooling) kPa 26 31 47 35 43 31 32 32 39 39 38 39 39 40
Available head, standard pump (cooling) kPa 157 149 125 131 117 129 129 128 118 118 119 109 109 106
Buffer tank dm
3
200 200 220 220 220 340 340 340 340 340 340 600 600 600
Expansion tank dm
3
12 12 12 12 12 12 12 12 12 12 12 24 24 24
Plumbing connections 222222 1/2 2 1/2 2 1/2 2 1/2 2 1/2 2 1/2 333
Height mm 1735 1735 1735 1735 1735 1735 1735 1679 1735 1735 1679 1847 1847 1847
Length mm 2090 2090 2442 2442 2442 3190 3190 3540 3190 3190 3540 3538 3538 3538
Depth mm 1183 1183 1183 1183 1183 1183 1183 1183 1183 1183 1183 1653 1653 1653
Sound power level dB(A) 67,0 71,0 73,0 73,0 73,0 70,0 74,0 70,0 70,0 74,0 70,0 69,0 73,0 69,0
Sound pressure level dB(A) 39,0 43,0 45,0 45,0 45,0 42,0 46,0 42,0 42,0 46,0 42,0 41,0 45,0 41,0
Base unit operating weight kg 525 525 630 635 700 905 905 980 915 915 980 1260 1260 1275
Unit with pump and full tank operating weight kg 862 862 982 987 1067 1426 1426 1557 1436 1436 1557 2040 2040 2055
Rated technical data of LCE heat pumps, QUIET (super low noise) version
90 100
400-3-50
