Page21of56
RG66006951‐Rev.01
RATEDTECHNICALDATAOFLEWWATERCHILLERS@12/7°C;40/45°C30%glyc.
Efficiencypack 1 2 1 2 1 2 1 2 1 2
LEWDS/DL 41 42 51 52 61 62 71 72 81 82
Coolingcapacity kW
43.06 43.06 50.6 50.6 57.9 57.8 65.7 65.8 75.5 75.5
Ratedabsorbedpower kW
12.8 12.8 15.2 15.2 16.8 16.8 19.5 19.5 21.5 21.5
Evaporator‐sidepressuredrops kPa
27 27 37 37 30 30 37 37 29 29
Evaporator‐sideflowrate l/h
7407 7311 8700 8702 9953 9946 11306 11316 12982 12970
Condenserpressuredrops kPa
51 51 71 71 55 55 71 71 53 53
Condenser‐sideflowrate l/h
10871 10650 12807 12811 14541 14534 16582 16595 18877 18865
Electricalpowersupply V/ph/Hz 400‐3N‐50Hz
Scrollcompressors/coolingcircuits No.
2/2 2/1 2/2 2/1 2/2 2/1 2/2 2/1 2/2 2/1
Victaulichydraulicconnections inches 21/2 21/2 21/2 21/2 21/2 21/2 21/2 21/2 21/2 21/2
Height mm
1594 1594 1594 1594 1594 1594 1594 1594 1594 1594
Length mm
1174 1174 1174 1174 1174 1174 1174 1174 1174 1174
Depth mm
772 772 772 772 772 772 772 772 772 772
Maximumcurrent(FLA) A 30.0 30.0 37.0 37.0 40.0 40.0 46.0 46.0 50.0 50.0
Boostercurrent(LRA) A 111.0 111.0 156.0 156.0 157.0 157.0 164.0 164.0 176.0 176.0
LRAwithsoft‐starterkit A 73.0 73.0 83.0 83.0 102.0 102.0 107.0 107.0 117.0 117.0
EER 3.36 3.36 3.33 3.33 3.45 3.44 3.37 3.37 3.51 3.51
ESEER 5.61 6.04 5.39 5.78 5.73 6.11 5.59 6.01 5.89 6.25
Refrigerantload kg
4 4 4 5 5 5 5 6 7 7
RATEDTECHNICALDATAOFLEWWATERCHILLERS@12/7°C;40/45°C30%glyc.
Efficiencypack 1 2 1 2 1 2 1 2 4
LEWDS/DL 91 92
111 112 131 132 141 142 144
Coolingcapacity kW
83.7 83.8 101.5 101.4 115.3 115.5 132.8 132.9 133.5
Ratedabsorbedpower kW
24.6 24.6 28.7 28.7 33.4 33.4 38.1 38.1 38.7
Evaporator‐sidepressuredrops kPa
35 35 30 30 37 37 35 35 35
Evaporator‐sideflowrate l/h
14400 14421 17451 17448 19833 19864 22848 22867 22957
Condenserpressuredrops kPa
67 67 55 55 71 71 65 65 67
Condenser‐sideflowrate l/h
21078 21098 25347 25338 28945 28973 33277 33292 33520
Electricalpowersupply V/ph/Hz 400‐3N‐50Hz
Scrollcompressors/coolingcircuits No.
2/2 2/1 2/2 2/1 2/2 2/1 2/2 2/1
4/2
Victaulichydraulicconnections inches 21/2 21/2 21/2 21/2 21/2 21/2 21/2 21/2 21/2
Height mm
1594 1594 1594 1594 1594 1594 1594 1594 1854
Length mm
1174 1174 1674 1674 1674 1674 1674 1674 2374
Depth mm
772 772 772 772 772 772 772 772 772
Maximumcurrent(FLA) A 61.0 61.0 70.0 71.0 79.0 79.0 91.0 91.0 92.0
Boostercurrent(LRA) A 203.0 203.0 238.0 275.0 244.0 244.0 289.0 289.0 197.0
LRAwithsoft‐starterkit A 137.0 137.0 176.0 210.0 182.0 182.0 224.0 224.0 140.0
EER 3.40 3.41 3.54 3.53 3.45 3.46 3.49 3.49 3.45
ESEER 5.81 6.25 6.05 6.48 6.00 6.43 5.90 6.17 6.09
Refrigerantload kg
7 7 13 12 13 12 15 13 15
