Galletti LEW CS/CL 042 [22/56] Lew ds dl 161 162 164 181 182 184 204 214
![Galletti LEW HS/HL 161 [22/56] Lew ds dl 161 162 164 181 182 184 204 214](/views2/1576370/page22/bg16.png)
Page22of56
RG66006951‐Rev.01
RATEDTECHNICALDATAOFLEWWATERCHILLERS@12/7°C;40/45°C30%glyc.
Efficiencypack
1 2 4 1 2 3 4 4
LEWDS/DL
161 162 164 181 182 184 204 214
Coolingcapacity kW
149.4 149.5 150 175 174.9 169.6 187 201.2
Ratedabsorbedpower kW
42.6 42.6 75.1 50 50 48.6 52.7 57.3
Evaporator‐sidepressuredrops kPa
38 38 38 40 40 38 38 43
Evaporator‐sideflowrate l/h
25700 25712 25806 30104 30078 29178 32165 34601
Condenserpressuredrops kPa
57 57 59 64 64 60 60 70
Condenser‐sideflowrate l/h
37388 37403 37539 43812 43775 42476 46666 50309
Electricalpowersupply V/ph/Hz 400‐3N‐50Hz
Scrollcompressors/coolingcircuits No.
2/2 2/1
4/2
2/2 2/1
4/2 4/2 4/2
Victaulichydraulicconnections inches 21/2 21/2 21/2 21/2 21/2 21/2 21/2 21/2
Height mm
1594 1594 1854 1594 1594 1854 1854 1854
Length mm
1674 1674 2374 1674 1674 2374 2374 2374
Depth mm
772 772 772 772 772 877 877 877
Maximumcurrent(FLA) A 102.0 102.0 100.0 116.0 116.0 122.0 132.0 142.0
Boostercurrent(LRA) A 298.0 298.0 211.0 361.0 361.0 250.0 321.0 328.0
LRAwithsoft‐starterkit A 233.0 233.0 152.0 278.0 278.0 184.0 256.0 263.0
EER 3.51 3.51 2.00 3.50 3.50 3.49 3.55 3.51
ESEER 5.80 6.17 6.24 5.84 6.29 6.33 6.46 6.44
Refrigerantload kg
15 13 15 16 15 22 24 27
RATEDTECHNICALDATAOFLEWWATERCHILLERS@12/7°C;40/45°C30%glyc.
Efficiencypack
3 4 3 4 4 4 4 4 4
LEWDS/DL
243 244 283 284 314 344 374 424 484
Coolingcapacity kW
231.8 240.2 266.2 269.4 298.3 321.4 349.1 386.7 442.05
Ratedabsorbedpower kW
63.6 65.6 75.2 75.9 86.3 93.3 100.4 109.2 126.57
Evaporator‐sidepressuredrops kPa
23 24 29 31 37 42 40 42 39
Evaporator‐sideflowrate l/h
39864 41306 45790 46344 51312 55284 60038 66514 75914
Condenserpressuredrops kPa
42 45 55 56 70 66 65 63 72
Condenser‐sideflowrate l/h
57517 59548 66463 67235 74861 80719 87499 96550 105646
Electricalpowersupply V/ph/Hz 400‐3N‐50Hz
Scrollcompressors/coolingcircuits No. 3/1 4/2 3/1 4/2 4/2 4/2 4/2 4/2 4/2
Victaulichydraulicconnections inches 21/2 21/2
3 3 3 3 3 3
3
Height mm
1854 1854 1854 1854 1854 1854 1854 1854 1854
Length mm
2374 2374 2374 2374 2374 2374 2374 2374 2374
Depth mm
877 877 877 877 877 877 877 877 877
Maximumcurrent(FLA) A 153.0 159.0 174.0 182.0 204.0 218.0 232.0 281.0 302.0
Boostercurrent(LRA) A 336.0 301.0 401.0 355.0 374.0 437.0 442.0 490.0 525.0
LRAwithsoft‐starterkit A 271.0 239.0 318.0 290.0 309.0 354.0 359.0 420.0 454.0
EER 3.64 3.66 3.54 3.55 3.46 3.44 3.48 3.54 3.22
ESEER 6.37 6.62 6.34 6.21 6.15 6.13 6.20 6.45 6.56
Refrigerantload kg
28 30 28 31 31 31 31 31 31
