Page25of56
RG66006951‐Rev.01
2.1 Performance of LEW C, D, H, W heat pump units
AllthedataintheparagraphreferstoΔT=5°Contheevaporationandcondensationside.Pf=chillerpower[kW];Pa
=absorbedpower[kW].InordertocalculatethethermodynamicEERandCOPfactors,takethePf/Paratio.The
performancewascalculatedwithdifferentglycolper
centagesinasolution,eventhoughfromathermodynamicpointof
view,withupto30%ofglycolinasolution,thereisaminorperformancedrop:nonethelessrefertoparagraph4.1“Use
ofglycolsolutions”forfurtherinformation.
TableIII:performanceofLEWCDHunitswithcoldwaterprod
uctionmode.
LEWC LEWD LEWH
Tcond
[°C]
10/30 15/30 20/30 30/35 35/40 40/45 10/30 15/30 20/30
Size
Tev
[°C]
Pf Pa Pf Pa Pf Pa Pf Pa Pf Pa Pf Pa Pf Pa Pf Pa Pf Pa
LEW
041/2
20/15 66.8 9.4 66.5 9.5 66.1 9.6 61.6 10 58.5 11.0 55.7 13 65.9 8.6 66.5 9.5 65.2 8.9
15/10 57.4 9.3 57.1 9.4 56.8 9.5 52.8 9.9 50.0 11.0 47.1 12.1 56.5 8.5 56.2 8.7 56.1 8.9
10/5 49 9.1 48.7 9.2 48.4 9.3 45.5 10.5 43.0 11.6 40.5 12.6 49.0 9.1 48.7 9.2 48.4 9.3
LEW
051/2
20/15 77.9 11.5 77.6 11.7 77 11.8 72.8 13.2 69.1 14.3 65.3 15.6 78.1 11.5 77.6 11.7 77.1 11.8
15/10 66.7 11.2 66.3 11.4 66 11.5 62.4 12.8 59.2 14.1 55.9 15.3 66.7 11.2 66.3 11.4 66.0 11.5
10/5 56.5 11 56.22 11.1 55.8 11.2 53 12.5 50.4 13.8 47.7 15 56.5 11.0 56.2 11.1 55.8 11.2
LEW
061/2
20/15 89 12.6 88.7 12.7 87.8 12.9 83.7 14.2 79.3 15.6 74.8 17.1 89.8 12.4 89.2 12.5 88.7 12.7
15/10 76.4 12.4 76.2 12.5 75.5 12.7 71.8 14 67.9 15.5 64 16.9 76.9 12.2 76.7 12.3 75.9 12.5
10/5 65.2 12.1 64.9 12.3 64.4 12.5 61.2 13.7 57.8 15.2 54.4 16.6 65.6 11.9 65.3 12.1 64.7 12.3
LEW
071/2
20/15 99.7 14.4 99 14.6 98.5 14.8 94.1 16.3 89.6 17.9 84.5 19.7 100.4 14.1 99.8 14.3 99.3 14.6
15/10 85.8 14.3 85.3 14.4 84.9 14.6 81 16.1 76.9 17.8 72.7 19.5 86.6 14.1 86.1 14.2 85.5 14.4
10/5 73.7 14 73.2 14.2 72.6 14.4 69.3 15.9 65.7 17.6 62.1 19.3 74.3 13.8 73.8 14 73.1 14.2
LEW
081/2
20/15 114.4 16.2 113.8 16.4 112.7 16.7 108.7 18 103.2 19.7 97.3 21.7 116.1 15.7 115.6 15.9 144.8 16.1
15/10 98.5 15.8 97.8 16.1 97.1 16.3 93.4 17.6 88.4 19.5 83.4 21.4 100.0 15.2 99.3 15.5 98.3 15.8
10/5 83.9 15.6 83.6 15.7 83 16 79.8 17.3 75.4 19.3 71 21.3 85.1 15.2 84.8 15.3 83.9 15.7
LEW
091/2
20/15 128.4 18 127.4 18.3 126.4 18.5 121.6 20.2 115.5 22.2 108.9 24.6 130.3 17.4 129.8 17.6 128.7 17.9
15/10 109.8 17.9 109.1 18.1 108.3 18.5 104.1 20 98.6 22.2 93 24.4 111.8 17.3 111.1 17.5 109.9 18.0
10/5 93.6 17.8 93 18 92 18.3 88.4 19.9 83.7 22.1 78.9 24.3 95.3 17.2 94.7 17.4 93.3 17.8
LEW
111/2
20/15 153.3 21.5 152.1 21.8 151.3 22.2 146.7 23.5 139.3 26.0 131.1 28.8 157.1 20.4 156.2 20.6 155.2 20.9
15/10 131.7 21.2 130.6 21.5 129.4 21.9 125.8 23.3 119.1 26.0 112.4 28.6 135.3 19.9 134.2 20.3 132.2 20.9
10/5 112.3 20.9 111.4 21.3 110.7 21.6 107.1 23 101.3 25.7 95.4 28.4 115.3 19.6 114.4 20.1 113.0 20.6
LEW
131/2
20/15 174.2 25 172.8 25.4 171.5 25.8 166.8 27.3 158.3 30.2 149.1 33.4 178.8 23.7 178 24 176.6 24.3
15/10 149.7 24.5 148.8 24.9 147.6 25.3 143.2 26.9 135.5 30.1 127.8 33.2 153.8 23.0 152.9 23.5 150.8 24.1
10/5 128 24.1 126.9 24.5 125.9 25 122 26.7 115.4 29.9 108.8 33 131.8 22.6 130.7 23.1 128.8 23.8
LEW
141/2
20/15 201.8 28.1 201.1 28.4 199.3 28.9 191.6 31.4 180.0 34.5 171.4 38.1 204.8 27.3 203.7 27.6 202.4 28.0
15/10 173.8 27.7 172.7 28 171.6 28.6 164.6 31 155.9 34.5 147.1 37.9 176.3 26.9 175.2 27.2 173.5 27.9
10/5 148.6 27.4 147.7 27.7 146.6 28.2 140.7 30.7 132.9 34.2 125.1 37.7 150.4 26.6 149.5 26.9 148.0 27.5
LEW
144
20/15 201.1 29 199.9 29.4 198.2 29.9 190.7 32.4 181.4 35.7 171.5 39.2 203.4 28.1 202.4 28.4 201.4 28.9
15/10 173.1 28.6 172.5 29 171 29.5 164.3 32 156.0 35.4 147.6 38.7 175.2 27.7 174.6 28.1 172.6 28.7
10/5 148.4 28.23 147.3 28.7 146.5 29 140.6 31.5 133.2 34.9 125.8 38.2 150.4 27.3 149.3 27.8 148.1 28.2
LEW
161/2
20/15 224.7 32 224 32.4 222.1 33 214.9 35.3 204.4 38.8 193.1 42.7 228.2 31.0 227.3 31.3 225.6 31.8
15/10 193.6 31.7 224.7 32.2 190.8 32.7 184.7 35 175.1 38.7 165.4 42.4 164.1 30.6 195.3 31.1 167.8 31.8
10/5 165.4 27.4 164.4 32 163.2 32.4 157.8 34.8 149.2 38.6 140.5 42.3 167.6 26.3 166.6 30.8 164.9 31.4
LEW
164
20/15 226.4 32.6 225.1 33 223.6 33.5 216.2 35.8 234.2 43.9 193.7 43.2 229.6 31.6 228.5 31.9 227.1 32.4
15/10 195.1 31.8 193.7 32.3 192.2 32.8 185.6 35.1 175.9 38.9 166.1 42.7 198.0 30.7 196.6 31.2 194.5 31.9
10/5 166.3 31.3 165.3 31.7 164.4 32 158.5 34.6 149.9 38.5 141.2 42.4 168.9 30.1 167.9 30.5 166.4 31.0
LEW
181/2
20/15 263.3 38 261.3 38.6 258.9 39.4 251.6 41.7 238.9 45.9 225.3 50.4 272.0 36.0 270.5 36.5 269.0 37.0
15/10 226.5 37.6 224.7 38.2 222.6 38.9 216.4 41.2 204.9 45.6 193.3 49.9 234.6 35.4 232.9 36.1 228.9 37.1
10/5 193.6 37.2 192.4 37.7 190.5 38.4 185.2 40.7 175.0 45.1 164.7 49.4 200.2 35.1 199.1 35.7 195.6 36.7
LEW
184
20/15 256.9 36.3 255.3 36.7 253.6 37.4 246.3 39.8 234.2 43.9 220.8 48.5 266.4 34.3 265.2 34.7 263.3 35.2
15/10 220.5 36 219.1 36.5 217.5 37.2 210.5 39.5 199.6 43.6 188.4 48.3 228.4 34.2 227.2 34.6 225.4 35.1
10/5 187.5 35.8 186.7 36.2 185.1 36.9 179.3 39.2 169.5 43.5 159.8 48.1 194.3 34 193.8 34.4 192.4 34.9
LEW
204
20/15 282.7 39.4 280.5 40.1 278.3 40.7 270.4 43.2 256.9 47.7 242.5 52.7 288.5 37.6 286.8 38.1 285.3 38.7
15/10 242.2 39 240.8 39.6 238.5 40.4 231.8 42.8 219.3 47.7 206.8 52.5 247.6 40.0 246.2 40.6 242.7 41.2
10/5 206.5 38.6 205.2 39.2 203.5 39.8 197.1 42.4 186.6 47.3 176 52.2 211.2 36.7 209.9 37.4 207.1 38.3
LEW
214
20/15 303.4 43 302.3 43.5 299.4 44.3 290.9 47 275.6 51.9 260.8 57.3 315.1 40.7 313.2 41.2 311.7 41.8
15/10 260.9 42.3 259.2 42.9 256.7 43.7 249.7 46.4 236.3 51.7 222.8 57 270.5 39.9 269 40.6 264.2 41.7
10/5 222.7 47 221.3 42.4 219 43.2 212.6 46 200.8 51.4 189 56.8 230.6 44.3 229.4 40.1 225.2 41.2
LEW
243
20/15 344.1 47.7 356 49.5 339.5 49.2 332.3 52.7 316.1 57.9 298.5 63.7 353.9 45.8 352.4 46.3 350.2 47.0
15/10 295.9 47.4 294.2 48 292 48.8 285.8 52.3 271.0 57.9 256.1 63.4 305.0 45.3 303.4 46 299.1 47.1
10/5 252.7 47 251.3 47.6 249.4 48.4 244.2 51.9 231.1 57.5 218 63 260.7 44.9 259.4 45.6 255.6 46.7
