307
galletti.com VM66000387-01
Total heat recovery multi-purpose heat pumps - LCP
LCP 52 - 314 kW
1653 3538
70
USER INTERFACE
(OPTIONAL)
1606
1847
344 1178 735
1178
101
1594
654 2356 526
1
2
3
8
266 250
278 1050 278
266 250
7
5
6
4
1 m
1 m
1,5 m
1,5 m
1,5 m
LCP 124 - 194
Dimensional drawings
LEGEND
1 Vibration dampers
2 Protective grille (optional)
3 Fastening points
4 Hot water inlet (Victaulic 3”)
5 Cold water inlet (Victaulic 3”)
6 Hot water outlet (Victaulic 3”)
7 Cold water outlet (Victaulic 3”)
8 Power supply input
Model Version
LCP 124 M-P S-L
LCP 144 M-P S-L
LCP 164 M-P S-L
LCP 194 M-P S-L
