308
galletti.com VM66000387-01
Total heat recovery multi-purpose heat pumps LCP
1653 3538
70
1549
2330*
344 1178 1179 735 100
201 3034 300
2076
* with EC FANS = 2367
1
2
3
8
9
= =1050
423
723
423
723
7
5
6
4
1 m
1 m
1,5 m
1,5 m
LCP 214 - 244
Dimensional drawings
LEGEND
1 Vibration dampers
2 Protective grille (optional)
3 Fastening points
4 Hot water inlet (Victaulic 4”)
5 Cold water inlet (Victaulic 4”)
6 Hot water outlet (Victaulic 4”)
7 Cold water outlet (Victaulic 4”)
8 Power supply input
9 User interface (optional)
Model Version
LCP 214 M-P S-L
LCP 244 M-P S-L
